Schneider Electric ATV61HU40N4 Variable Speed Drive

Schneider Electric ATV61HU40N4 Variable Speed Drive

Key Product Specifications

• Brand & Model: Schneider Electric ATV61HU40N4
• Motor Power: Rated for 4 kW (5 HP) three-phase motors
• Supply Voltage: 380-480V AC, 3-phase, 50/60 Hz compatible
• Line Current: Rated at 5.4 A for continuous operation
• Apparent Power: 5.5 kVA capacity for motor control
• Control Type: Advanced variable speed drive technology
• Transient Capacity: Handles up to 7.5 A for 60 seconds during overloads

Technical Performance Details

• Switching Frequency: 12 kHz nominal, adjustable from 1 to 16 kHz
• EMC Protection: Features an integrated EMC filter for electromagnetic compatibility
• Thermal Management: Designed with heat sink for effective heat dissipation
• Frequency Compatibility: Works with both 50 Hz and 60 Hz supply systems
• Protection Rating: Rated IP20 for basic protection against dust and contact

Physical & Environmental Specifications

• Weight: Unit weighs approximately 11.34 kg (25 lbs)
• Enclosure: IP20 rating suitable for indoor industrial environments
• Assembly: Designed with integrated heat sink for optimal thermal performance
• Application: Ideal for industrial applications requiring variable motor speed control
• Compatibility: Works with standard three-phase industrial motors

Packaging & Shipping Information

• Package Includes: One (1) brand new, original ATV61HU40N4 drive in factory packaging
• Shipping: Orders processed within 5 business days, shipped via DHL, FedEx, or UPS
• Return Policy: 30-day return available for unused items in original condition

Frequently Asked Questions (FAQ)

• Q: Is the ATV61HU40N4 new and available immediately?
  A: Yes, this ATV61HU40N4 is brand new and original, and we have it in stock for immediate shipping.
• Q: What motor size can this drive control?
  A: The ATV61HU40N4 controls three-phase motors up to 4 kW (5 horsepower).
• Q: What input voltage does it require?
  A: It requires a three-phase 380-480V AC power supply at either 50 Hz or 60 Hz.
• Q: Does it include EMC protection?
  A: Yes, it features an integrated EMC filter to reduce electromagnetic interference.
• Q: Can the switching frequency be adjusted?
  A: Yes, the switching frequency is adjustable from 1 kHz to 16 kHz to optimize performance.
• Q: What is the protection rating?
  A: It has an IP20 rating, providing basic protection against dust and accidental contact.
• Q: How is it shipped and how long does delivery take?
  A: We ship via major carriers like DHL, FedEx, or UPS within 5 days, with delivery time depending on destination.
