Schneider Electric 140DAI54000 | Discrete Input Module

Schneider Electric 140DAI54000 Discrete Input Module

Core Technical Specifications

• Brand & Model: Schneider Electric 140DAI54000.
• Product Type: 115 V AC Discrete Input Module for Modicon Quantum.
• Channel Count: 16 individual input channels in one group.
• Input Voltage (State 1): 79-132 V AC at 57-63 Hz.
• Input Voltage (State 0): 0-20 V AC for reliable off-state detection.
• Input Current: Approximately 11.1 mA at 60 Hz and 13.2 mA at 50 Hz.
• Network Frequency: Wide operational range from 47 to 63 Hz.
• Input Impedance: 12 kΩ capacitive at 60 Hz for minimal load.

Performance & Environmental Ratings

• Response Time: Fast Off to On response between 0.75 and 4.9 ms per line cycle.
• Isolation: High 1780 Vrms isolation between channels and from the backplane bus.
• Operating Temperature: Reliable performance from 0°C to 60°C (32°F to 140°F).
• EMC Robustness: Resists electrostatic discharge up to 8 kV air / 4 kV contact.
• Operating Altitude: Suitable for installations up to 5000 meters.
• Power Consumption: Requires 180 mA from the bus with 5.5 W dissipation.

Design & Installation Features

• Addressing: Simple configuration requiring only 1 input word.
• Status Indication: 16 green LEDs for channel status, plus bus and fault LEDs.
• Module Format: Standard Quantum form factor for easy rack mounting.
• Safety Certifications: Complies with UL 508, CSA C22.2 No. 142, and cUL standards.
• Hazardous Location: FM Class 1 Division 2 certification for versatile use.

Frequently Asked Questions (FAQ)

• Q: What is the voltage rating for the 140DAI54000 inputs?
  A: This module accepts 115V AC input signals, with a guaranteed "ON" state between 79-132V AC.
• Q: How many input points does this Quantum module have?
  A: The Schneider Electric 140DAI54000 provides 16 discrete AC input channels.
• Q: What is the response time of this input module?
  A: The Off to On response time is very fast, between 0.75 ms and 4.9 ms per line cycle.
• Q: Do you have this module in stock for immediate shipment?
  A: Yes, we stock the 140DAI54000 and typically ship within 5 business days.
• Q: What software can I use to program this module?
  A: It is compatible with Schneider Electric's Unity Pro, Concept, and ProWORX 32 software packages.
• Q: What is your return policy for this item?
  A: We offer a 30-day return policy for this product from the date of delivery.

For technical specifications, pricing, and availability of the Schneider Electric 140DAI54000, please contact our sales team.

Contact Information & Inquiries: Email us at sales@nex-auto.com or call/message us on +86 153 9242 9628 via WhatsApp.

Partner: NexAuto Technology Limited
