Schneider 140DDO84300C 16-Channel DC Output Module

Schneider Electric 140DDO84300C Modicon Quantum DC Output Module Overview

• Detailed Technical Specifications: The 140DDO84300C module supports an output voltage range of 10 to 60 Volts DC, with limits extending from 10.2 to 72 Volts. Each channel group features an 8 Ampere internal fuse for robust overcurrent protection. We rate the absolute maximum permanent output voltage at 72 Volts, safeguarding your system against surges. The module maintains a very low leakage current of less than 1 milliampere, ensuring signal integrity when outputs are off. Power dissipation is approximately 1 Watt plus the load voltage drop, promoting energy efficiency.
• Performance and Response Characteristics: Users can rely on rapid switching with a response time of less than or equal to 1 millisecond for both turn-on and turn-off states. The maximum voltage drop is below 1 Volt at a 2 Ampere load, ensuring efficient power delivery to field devices. It can handle a surge current of 7.5 Amperes for 50 microseconds, accommodating inrush currents from inductive loads. The required bus current from the backplane is 160 milliamperes, which helps in calculating overall system power budgets accurately.
• Environmental and Physical Attributes: This Quantum series module operates dependably in ambient temperatures ranging from 0 to 60°C without condensation. It survives storage in extreme conditions from -40 to 85°C, demonstrating its durability. The module includes a conformal coating (Humiseal 1A33) for protection against moisture and contaminants. It weighs 0.45 kg and comes in a standard Modicon Quantum form factor for easy installation in your rack system.
• Diagnostic and Safety Features: Local signaling includes 17 green LEDs and one red LED for immediate visual feedback. Sixteen green LEDs indicate the status of each individual output point. One green LED shows active bus communication, while the red LED signals an external fault. Isolation is robust with 2500 Vrms DC between channels and the bus, and 700 Vrms DC between groups for one minute. These features comply with standards such as UL 508 and CSA C22.2 No 142.
• Package Contents and Logistics: We ship the 140DDO84300C in a single PCE-type package measuring 31.2 cm in length, 4.5 cm in width, and 16.3 cm in height. The total packaged weight is 680.0 grams, ensuring safe transit. We stock this item as brand new and original, ready for immediate dispatch. Our logistics partners include FedEx, UPS, and DHL for reliable worldwide delivery.

Frequently Asked Questions (FAQ)

• What is the output configuration of the 140DDO84300C?
  The 140DDO84300C features 16 discrete outputs arranged into two channel groups of eight. It operates using positive logic, functioning as a sourcing (source) output module for DC applications.
• Is this module brand new and original, and how do you handle shipping?
  Yes, we supply the 140DDO84300C as a brand new, genuine Schneider Electric product. We maintain this item in stock and typically dispatch orders within 5 days using trusted carriers like DHL, UPS, or FedEx.
• What protection does the module offer for connected devices?
  Each of the two output groups has internal protection via an 8 Ampere fuse. Additionally, each individual point has an associated 2 Ampere fuse rating, providing comprehensive overcurrent safeguarding for your field wiring and actuators.
• What are the voltage limits for safe operation?
  The nominal output voltage rating is 10 to 60 Volts DC, but the operating limits extend from 10.2 to 72 Volts DC. The absolute maximum permanent output voltage is 72 Volts, ensuring the module tolerates voltage fluctuations without damage.
• Can I return this item if I have issues with my order?
  We support returns within 30 days of receipt. Please ensure the item is in its original condition and packaging. Contact our sales team to initiate the process.
