Probes | Bently Nevada | 330106-05-30-90-02-05

In stock (12 units), ready to be shipped
  • Vendor:

    Bently Nevada

  • Type:

    Proximity Probes

  • Country of Origin:

    USA

  • Dimensions:

    24*25*5cm

  • Weight:

    2907 g

  • Tags: Reverse mount probes

Bently Nevada 330106-05-30-90-02-05 Reverse Mount Probes

Technical Specifications

  • Brand & Model: Bently Nevada 330106-05-30-90-02-05
  • Thread Configurations: Model 330105 uses 3/8-24 UNF dual threads, Model 330106 uses M10 x 1 threads for heavy-duty mounting
  • Cable Type: 9.0-meter PTFE-jacketed cable (29.5 ft), weight 323 g/m
  • Linearity Tolerance: ±1.5% across -40°C to +85°C operating range
  • Dielectric Strength: 1000V RMS, minimum 25mm bend radius
  • Connectors: IP67-rated ClickLoc, tested for 500+ mating cycles

Performance Data

  • Frequency Response: 5 Hz to 2 kHz with 24 AWG silver-plated conductors
  • Vibration Resistance: 15G (10–2000 Hz), humidity tolerance 98%
  • Installation Torque: 2.5 Nm recommended for thread durability
  • Operational Voltage: 250V AC/DC, signal loss 0.8 dB/m at 100 kHz
  • Total System Weight: 2.907 kg (6.4 lbs)
  • Certifications: CSA Cl I Div 2, ATEX Zone 2, IECEx Ex ia IIC T4
