Lenze EVF9328-CVV003 30kW Frequency Inverter

Lenze EVF9328-CVV003 Frequency Inverter

Core Electrical Specifications

The EVF9328-CVV003 provides precise control with strong power handling.

• The unit has a voltage rating of 400 VAC for standard industrial power systems.
• It accepts a wide AC mains voltage input from 320 to 440 VAC for flexibility.
• The input frequency operates within a range of 45 Hz to 65 Hz.
• Its typical motor power is 30 kW, equivalent to 40 horsepower.
• The inverter delivers a maximum output power of 32.6 kVA at an 8 kHz switching frequency.

Current Ratings and Performance

This Lenze inverter handles significant current loads for powerful motors.

• The rated output current is 47A at 8 kHz for 400V operations.
• It supports a maximum permissible output current of 70.5A at 2/4/8 kHz for peaks.
• The main circuit can reach 50A when using a mains choke at 400V.
• The unit has a power loss rating of 610 W, indicating its efficiency under load.

Packaging and Shipping Information

We deliver your product quickly and securely to your location.

• Packaging List: Includes the EVF9328-CVV003 inverter unit, user manual, and necessary hardware.
• Shipping Methods: We use reliable global carriers like FedEx, UPS, and DHL.
• Delivery Time: Orders are processed and shipped from available stock within five business days.

Frequently Asked Questions (FAQ)

• Is this Lenze inverter new and original? Yes, we supply only 100% brand new and original Lenze products.
• What is the power rating of this model? It is rated for a typical motor power of 30 kW or 40 HP.
• What is the required input voltage? It requires a 3-phase AC input between 320V and 440V at 45-65 Hz.
• What does "Cold Plate version" mean? It indicates an integrated cooling plate for efficient heat dissipation without a separate fan.
• What is the maximum output current? The drive can deliver up to 70.5A maximum current at lower switching frequencies.
• Is this item in stock? Yes, the EVF9328-CVV003 is typically available from our current stock.
• What is your return policy? We provide a 30-day return policy for items in new, unused condition.

For more information on the EVF9328-CVV003 or other drives in the Lenze Series 9300, please get in touch. Partner NexAuto Technology Limited: https://www.nex-auto.com/

Contact Information Inquiries: sales@nex-auto.com | +86 153 9242 9628
