IS220UCSAH1A GE - Mark VIe Controller

IS220UCSAH1A PAMC Acoustic Monitor Processor – Mark VIe Controller

• Brand: General Electric (GE Energy).
• Model: IS220UCSAH1A.
• Series: Mark VIe (Mark VI Series).
• Functional Acronym: UCSA – PAMC Acoustic Monitor (Processor).
• Product Type: Mark VIe Controller.
• PCB Coating: Standard conformal coating for component protection.
• Instruction Manual: GEH-6725R.
• Applications: Mark VIe, Mark VIes, EX2100e, LS2100e.

Technical Specifications & Core Features

• Processor: Freescale PowerQUICC II Pro 8349 running at 667 MHz.
• Memory: 256 MB DDR SDRAM for robust data handling.
• Operating System: QNX Neutrino for real-time turbine control.
• Software: ControlST V04.03.18C for system configuration.
• Power Requirements: 18–36 V DC, 12 watts nominal consumption.
• Ethernet Ports: Six ports for extensive network connectivity.
• Operating Temperature: 0 to 65 °C (32 to 149 °F) – fanless cooling design.
• Relative Humidity: 5% to 95%, non-condensing.
• Safety Rating: NFPA Class 1, Division 2 for hazardous locations.
• Weight: 2 lbs (0.9 kg) – compact and lightweight.
• Country of Origin: United States (USA).

Frequently Asked Questions (FAQ)

• Q: Is this unit brand new or used?
  A: This IS220UCSAH1A is new surplus in the original factory package.
• Q: Do you have this item in stock?
  A: Yes, we maintain stock available for immediate order processing.
• Q: What is the shipping time after I place an order?
  A: We dispatch within 5 days – delivery depends on your location and carrier choice.
• Q: Which carriers do you use?
  A: We ship with DHL, FedEx, and UPS – select your preference.
• Q: Can I return this controller if it doesn't fit my system?
  A: Yes, we accept returns within 30 days from delivery (conditions apply).
• Q: Does this unit require a fan for cooling?
  A: No, the IS220UCSAH1A uses passive cooling – even at 65 °C.
• Q: Is this compatible with EX2100e systems?
  A: Yes, it supports EX2100e, LS2100e, Mark VIe, and Mark VIes applications.
• Q: What operating system does this run?
  A: It runs the QNX Neutrino real-time operating system.
