Honeywell TC-IXR061 RTD Input Module | 6-Point Isolated

Honeywell TC-IXR061 RTD Input Module – 6-Point Isolated Industrial Solution

Key Technical Specifications

• Brand: Honeywell
• Model: TC-IXR061
• Category: RTD Input Module (6-Point, Isolated)
• Number of Points: 6 galvanically isolated channels
• Signal Input Ranges: 1–487 Ω, 2–1000 Ω, 4–2000 Ω, 8–4020 Ω
• Supported Sensors: 100/200/500/1000 Ω Platinum (α = 0.00385 and 0.003916), 120 Ω Nickel (α = 0.00672), 100/120/200/500 Ω Nickel (α = 0.00618), 10 Ω Copper
• Resolution: 16 bits across each input range
• Resolution per Bit: 7.7 mΩ/bit for 487 Ω, 100 Ω Pt, 100 Ω Ni, 10 Ω Cu; 15 mΩ/bit for 1000 Ω, 200 Ω Pt, 200 Ω Ni; 30 mΩ/bit for 2000 Ω, 500 Ω Pt, 500 Ω Ni; 60 mΩ/bit for 4020 Ω, 1000 Ω Pt
• Accuracy: 0.1% FS @ 25°C
• Module Update Rate: 50 milliseconds for all channels
• Settling Time: Less than 80 milliseconds to 5% of full scale
• Open Wire Detection: Reports out-of-range reading; detection time less than 5 seconds
• Common Mode Rejection: 120 dB @ 60 Hz, 100 dB @ 50 Hz
• Channel Bandwidth: DC to 15 Hz (-3 dB)
• Normal Mode Noise Rejection: 60 dB @ 60 Hz
• RFI Immunity: Error less than 2.0% of FS at 10 V/m, 27 to 1000 MHz
• Input Offset Drift: 10 mΩ/°C typical
• Gain Drift: 50 ppm/°C typical
• Power Dissipation: 4.3 W maximum
• Isolation Voltage: Channel to channel and user to system, 100% tested at 2546 VDC for 1 second
• Connection Terminal Blocks: TC-TBNH, 20-position terminal block

Installation Guide

• Mount the TC-IXR061 module in a compatible Honeywell backplane or chassis slot.
• Use the TC-TBNH 20-position terminal block for all field wiring connections.
• Keep RTD sensor leads short and shielded to reduce noise pickup.
• Verify channel-to-channel isolation before powering the system.
• Allow at least 80 milliseconds for signal settling after a range change.
• Check open wire detection by disconnecting one sensor lead and monitoring the reading.

Package Contents

• 1 x Honeywell TC-IXR061 RTD Input Module
• 1 x TC-TBNH 20-position terminal block (if ordered together)
• Product documentation is available online

Shipping and Support

• We keep this module in stock for immediate order processing.
• We ship within 5 days using FedEx, UPS, DHL, or other common carriers.
• We accept returns within 30 days for eligible items.
• All units are brand new and original.

Frequently Asked Questions

• Q: What sensor types does the TC-IXR061 support?
  A: It supports 100–1000 Ω platinum, 100–500 Ω nickel, and 10 Ω copper RTDs.
• Q: How many isolated channels does this module have?
  A: It provides 6 galvanically isolated input channels.
• Q: What is the module update rate?
  A: The update rate is 50 milliseconds for all channels.
• Q: Does it detect broken sensor wires?
  A: Yes, it reports an out-of-range reading and detects open wires in under 5 seconds.
• Q: What is the accuracy at room temperature?
  A: Accuracy is 0.1% of full scale at 25°C.
• Q: Which terminal block fits this module?
  A: Use the TC-TBNH 20-position terminal block.
• Q: How fast do you ship?
  A: We ship within 5 days via FedEx, UPS, or DHL.
• Q: Can I return the module?
  A: Yes, we support 30-day returns for eligible orders.
