Honeywell TC-IAH161 High Level Analog Module | 10V 4-20mA

Honeywell TC-IAH161 High Level Analog Input Module – 16-Channel Voltage and Current

Key Technical Specifications

• Brand: Honeywell
• Model: TC-IAH161
• Category: High Level Analog Input Module
• Number of Points: 16 channels
• Input Voltage Range: ±10.25 V, 0 to 10.25 V, 0 to 5.125 V
• Input Current Range: 0 to 20.5 mA (internal 250 Ω resistor)
• Voltage Resolution: 320 µV on ±10.5 V range, 160 µV on 0–10.5 V range, 80 µV on 0–5 V range
• Current Resolution: 320 µA
• Resolution: 16 bits across each range
• Module Publish Rate: 250 milliseconds
• Input Impedance (Voltage): Greater than 1.0 MΩ
• Input Impedance (Current): 249 Ω nominal
• Open Circuit Detection: Voltage uses even channels for positive full scale and odd channels for negative full scale; current reports negative full scale
• Typical OC Detection Time: Less than 5 seconds
• Normal Mode Noise Rejection: Greater than 33 dB @ 50 Hz, greater than 60 dB @ 60 Hz
• Common Mode Rejection: 100 dB @ 50/60 Hz
• Channel Bandwidth: 20 Hz (-3 dB)
• Calibrated Accuracy @ 25°C: Better than 0.05% of range for voltage, better than 0.15% of range including sense resistor for current
• RFI Immunity: Error less than 2.0% of range at 10 V/m, 27 to 1000 MHz
• Overvoltage Capability: 30 VDC continuous for voltage, 8 VDC continuous for current at room temperature
• Input Offset Drift: Less than 90 µV/°C for voltage, less than 360 nA/°C typical for current
• Gain Drift: 15 ppm/°C for voltage, 20 ppm/°C for current
• Module Error Over Full Temp Range: 0.1% of range for voltage, 0.3% of range for current
• Power Dissipation: 4.1 W maximum
• Isolation Voltage: User to system, 100% tested at 2550 VDC for 1 second
• Connection Terminal Blocks: TC-TBCH, 36-position terminal block

Installation Guide

• Insert the TC-IAH161 module into a compatible Honeywell backplane slot.
• Use the TC-TBCH 36-position terminal block for all field wiring.
• Keep voltage and current input wires separated to reduce cross-talk.
• Confirm the internal 250 Ω sense resistor for current loops before wiring.
• Allow 250 milliseconds for the module to publish updated channel data.
• Test open circuit detection by removing one input lead and checking the reading.

Package Contents

• 1 x Honeywell TC-IAH161 High Level Analog Input Module
• 1 x TC-TBCH 36-position terminal block (if ordered together)
• Product documentation is available online

Shipping and Support

• We keep this module in stock for immediate order processing.
• We ship within 5 days using FedEx, UPS, DHL, or other common carriers.
• We accept returns within 30 days for eligible items.
• All units are brand new and original.

Frequently Asked Questions

• Q: What signal types does the TC-IAH161 accept?
  A: It accepts voltage up to ±10.25 V and current from 0 to 20.5 mA.
• Q: How many channels does this module provide?
  A: It offers 16 separate input channels in one module.
• Q: What is the resolution of the TC-IAH161?
  A: It provides 16-bit resolution across each input range.
• Q: How often does the module update data?
  A: The module publish rate is 250 milliseconds.
• Q: Does it detect open circuits?
  A: Yes, it detects open circuits in less than 5 seconds.
• Q: What terminal block fits this module?
  A: Use the TC-TBCH 36-position terminal block.
• Q: What is the accuracy at 25°C?
  A: Voltage accuracy is better than 0.05% of range, and current accuracy is better than 0.15%.
• Q: How fast do you ship?
  A: We ship within 5 days via FedEx, UPS, or DHL.
• Q: Can I return the module?
  A: Yes, we support 30-day returns for eligible orders.
