ETR Proximity Probes | Bently Nevada 330191-40-75-90-05

Bently Nevada 3300 XL Explosion-Proof Proximity Probe

Product Overview & Core Specifications

• Brand & Model: This is an 8mm proximity probe from the Bently Nevada 3300 XL series.
• Full Part Number: The exact model identifier is 330191-40-75-90-05.
• Mounting: It features a standard 3/8-24 UNF threaded connection for secure installation.
• Cable Length: The probe includes a generous 9-meter (29.5 ft) integrated cable.
• Safety Certification: This model carries full CSA, ATEX, and IECEx explosion-proof certifications.

Detailed Model Number Breakdown

• 40: This indicates a 4.0-inch (101.6 mm) unthreaded probe length.
• 75: This specifies a 7.5-inch (190.5 mm) total metal case length.
• 90: This denotes the integrated 9.0-meter cable length.
• 05: This suffix confirms the probe has hazardous area safety approvals.

Key Performance Features

• Operating Voltage: It requires a -17.5V to -26V DC power supply.
• Temperature Range: The probe operates from -55°C to +232°C (-67°F to +450°F).
• Cable Option: An optional FluidLoc oil-blocking cable is available for wet environments.
• Connection Quality: It uses gold-plated connectors for superior corrosion resistance.
• Cable Strength: The cable can withstand a pull force exceeding 75 lbs (34 kg).

Package Contents

• One complete Bently Nevada 330191-40-75-90-05 proximity probe assembly.
• A clear installation and mounting guide for correct setup.
• All necessary factory documentation and calibration records.
• Download the official datasheet for full details: 3300 XL 8mm Proximity Transducer System Datasheet.

Frequently Asked Questions (FAQ)

• Is this probe certified for hazardous areas?
  Yes, the 330191-40-75-90-05 is CSA, ATEX, and IECEx certified for explosive atmospheres.
• What is the operating temperature range?
  It functions reliably from -55°C to +232°C, suitable for extreme environments.
• Is the product new and in stock?
  We supply only brand new, genuine Bently Nevada products from available stock.
• What is your shipping policy?
  We ship globally via DHL, FedEx, or UPS within 5 business days.
• Do you offer technical support?
  Yes, this probe requires professional setup. We recommend using it only with compatible Bently Nevada monitors.
• What is the return policy?
  We offer a 30-day return policy for unused items in original packaging.

For complete specifications on the explosion-proof Bently Nevada 330191-40-75-90-05, please download the datasheet. Contact our sales team for pricing and application support.
