EDS-208A Moxa 8-Port DIN-Rail Aluminum Switch

EDS-208A Unmanaged 8-Port Industrial Ethernet Switch by Moxa

Technical Specifications

• Brand: Moxa
• Model: EDS-208A
• Series: EDS-208 Series
• Switch Type: Unmanaged, DIN-rail form factor
• RJ45 Ports: 8 × 10/100BaseT(X) with auto-negotiation and auto MDI/MDI-X
• Fiber Ports: None
• MAC Table Size: 2 K entries
• Packet Buffer: 0.768 Mbits
• Processing: Store and Forward
• Protocols: IEEE 802.3, 802.3u, and 802.3x flow control
• Redundancy and Management: Not supported (unmanaged design)
• Supply Voltage: 12/24/48 VDC nominal, 9.6 to 60 VDC operating range
• Power Inputs: Redundant dual inputs
• Input Current: 0.11 A max at 24 VDC
• Overload Current Protection: Supported
• Reverse Polarity Protection: Supported
• Operating Temperature: -10 to 60 °C (standard)
• Storage Temperature: -40 to 85 °C (package included)
• Humidity: 5 to 95% non-condensing
• Protection Rating: IP30
• Dimensions (H×W×D): 50 × 114 × 70 mm
• Weight: 0.275 kg
• Mounting: DIN-rail; wall mounting with optional kit
• Enclosure: Aluminum, IP30
• Lifecycle Status: Current (last verified 2026-09)

Installation Guide

• Mount the switch on a standard 35 mm DIN rail inside a protected cabinet.
• Use the optional wall mounting kit when cabinet space limits DIN-rail access.
• Wire both power inputs to separate 12/24/48 VDC sources within the 9.6 to 60 VDC range.
• Confirm reverse polarity protection engages before energizing the redundant feeds.
• Attach RJ45 cables to any of the eight auto MDI/MDI-X ports without crossover concerns.
• Keep the aluminum IP30 enclosure clear of moisture and excessive dust buildup.
• Verify ambient temperature stays inside the -10 to 60 °C operating range.

Package Contents

• 1 × Moxa EDS-208A unmanaged Ethernet switch
• 1 × DIN-rail mounting kit
• 1 × Quick installation guide
• Shipping via FedEx, UPS, or DHL according to your preference

FAQ

• Q: Does the EDS-208A offer redundant power inputs? A: Yes, it provides dual power inputs for added supply reliability.
• Q: What voltage range does the switch accept? A: It accepts 12/24/48 VDC nominal with a 9.6 to 60 VDC operating range.
• Q: Does the aluminum housing support wall mounting? A: Yes, an optional kit enables wall mounting beyond the standard DIN rail.
• Q: What is the operating temperature range? A: The switch runs reliably from -10 to 60 °C.
• Q: Are fiber ports available on this model? A: No, the EDS-208A provides eight copper RJ45 ports only.
• Q: Does the switch require configuration? A: No, it is unmanaged and works immediately after power-up.
• Q: What are the stock and shipping terms? A: We hold new original stock and ship within 5 days via DHL and similar carriers.
• Q: What is the return policy? A: We support 30-day returns on all orders.
