Bently Nevada 330709-000-040-10-11-00 3300 XL Probe

  Bently Nevada 330709-000-040-10-11-00 Proximity Probe – 3300 XL 11 mm Series

Key Technical Specifications

• Brand: Bently Nevada
• Model: 330709-000-040-10-11-00
• Series: 3300 XL 11 mm Proximity Probes
• Probe DC Resistance: 5.9 ± 0.5 ohms from center conductor to outer conductor
• Total Length: 1.0 metre (3.3 feet)
• Probe Case Thread: M16 x 1.5
• Maximum Thread Engagement: 24 mm
• Unthreaded Length: 0 mm
• Overall Case Length: 40 mm
• Connector Type: Miniature coaxial ClickLoc connector with protector, FluidLoc cable
• Agency Approval: Not required
• Probe Tip Material: Polyphenylene sulfide (PPS)
• Probe Case Material: AISI 304 stainless steel (SST)
• Cable Specification: 75 Ω triaxial, FEP insulated
• Minimum Bend Radius: 25.4 mm (1.0 in)
• Probe Case Torque: Maximum 63.3 N•m (560 in•lb); Recommended 21.1 N•m (187 in•lb)
• Connector-to-Connector Torque: Finger tight recommended; maximum 0.565 N•m (5 in•lb)
• Operating and Storage Temperature: -52°C to +177°C (-62°F to +351°F)
• Temperature Note: Exposing the probe below -34°C may cause premature pressure seal failure

Temperature Classification (Probe Only)

• For EPL Ga and Gc: T1: -55°C to +232°C; T2: -55°C to +177°C; T3: -55°C to +120°C; T4: -55°C to +80°C; T5: -55°C to +40°C
• For EPL Dc: T280°C @ Ta: -55°C to +232°C; T225°C @ Ta: -55°C to +177°C; T170°C @ Ta: -55°C to +120°C; T130°C @ Ta: -55°C to +80°C; T105°C @ Ta: -55°C to +100°C; T90°C @ Ta: -55°C to +40°C

Cross-talk and Target Requirements

• Target Size – Flat Surface Diameter: Recommended minimum 30.5 mm (1.2 in)
• Shaft Diameter: Recommended minimum 152 mm (6.0 in)
• These values help reduce cross-talk and maintain signal integrity

Installation Guide

• Mount the probe using the M16 x 1.5 thread and keep thread engagement under 24 mm
• Apply 21.1 N•m (187 in•lb) as the recommended case torque
• Never exceed 63.3 N•m (560 in•lb) to avoid damaging the probe case
• Keep the cable bend radius at or above 25.4 mm (1.0 in) during routing
• Hand-tighten the connector and avoid exceeding 0.565 N•m (5 in•lb)
• Verify the target size and shaft diameter meet the recommended minimums
• Confirm the probe DC resistance stays within 5.9 ± 0.5 ohms before operation

Package List

• 1 x Bently Nevada 330709-000-040-10-11-00 Proximity Probe
• 1 x Miniature coaxial ClickLoc connector with protector
• 1 x FluidLoc cable, 1.0 metre total length
• Protective packaging for safe transport

Shipping and Support

• We keep this item in stock and dispatch within 5 days
• We ship via FedEx, UPS, and DHL
• We accept returns within 30 days
• All products are brand new and original

FAQ

• Q: What is the probe DC resistance?
  A: The resistance from the center conductor to the outer conductor is 5.9 ± 0.5 ohms.
• Q: What is the operating temperature range?
  A: The probe operates and stores from -52°C to +177°C (-62°F to +351°F).
• Q: What thread size does the probe case use?
  A: The probe case uses an M16 x 1.5 thread with a maximum engagement of 24 mm.
• Q: What is the recommended case torque?
  A: The recommended torque is 21.1 N•m (187 in•lb), and the maximum is 63.3 N•m (560 in•lb).
• Q: What is the minimum bend radius?
  A: The minimum bend radius is 25.4 mm (1.0 in), with or without SST armor.
• Q: What target size do you recommend?
  A: For a flat surface, use a minimum diameter of 30.5 mm (1.2 in). For a shaft, use a minimum diameter of 152 mm (6.0 in).
• Q: How long is the probe cable?
  A: The total probe length is 1.0 metre (3.3 feet).
• Q: What connector type does this probe use?
  A: It uses a miniature coaxial ClickLoc connector with a protector and a FluidLoc cable.
