Bently Nevada - 3300 NSv Extension Cable - 330930-060-01-00

Bently Nevada 330930-060-01-00 Extension Cable for 3300 XL NSv Systems

Core Technical Specifications

• Brand & Model: Bently Nevada 330930-060-01-00
• Cable Type & Origin: 3300 NSv Extension Cable, 75-ohm coaxial, Made in U.S.A.
• Construction & Material: Features a stainless steel armor and an outer FEP jacket for maximum durability and chemical resistance.
• Operating Temperature: Withstands an extreme range from -51°C to +177°C (-60°F to +351°F).
• Electrical Specifications: Center conductor resistance: 0.220 Ω/m. Shield resistance: 0.066 Ω/m. Capacitance: 69.9 pF/m.
• Weight: Approximately 1.5 Kg, providing a robust yet manageable cable assembly.

Installation & System Wiring Guidelines

• Critical Rule: The extension cable length plus the probe length must equal the total required sensor length for accurate calibration.
• Connection Cable: Use a shielded triad cable with conductor sizes between 0.2–1.5 mm² (16–24 AWG).
• Maximum Run Length: Keep the wiring between the monitor and transducer system under 305 meters (1,000 feet) to ensure signal integrity.
• Installation Tip: Ensure all connections are secure and properly shielded to maximize the system's anti-interference capability.

Packaging & Shipping Information

• Packaging List: Your order includes one (1) genuine Bently Nevada 330930-060-01-00 6.0-meter extension cable.
• Item Condition: We supply only 100% brand new, genuine, and original factory components.
• Stock Status: This item is in stock in our warehouse and available for immediate shipment.
• Shipping: We process and dispatch orders within 5 business days using reliable global carriers like FedEx, UPS, or DHL.
• Returns Policy: We offer a straightforward 30-day return policy for your complete peace of mind.

Frequently Asked Questions (FAQ)

• Q: Is this cable compatible with all 3300 XL NSv probes?
  A: Yes, the 330930-060-01-00 is designed as the standard extension cable for the Bently Nevada 3300 XL NSv proximity transducer system.
• Q: Can I use this cable in high-temperature environments?
  A: Absolutely. With an FEP jacket and a rated operating temperature up to +177°C (351°F), it is suitable for most demanding applications.
• Q: What is the significance of the "total sensor length" rule?
  A: The monitoring system is calibrated for a specific total electrical length. The probe and extension cable together must match this length for accurate gap voltage and measurement readings.
• Q: Do you provide the connector mating assembly?
  A: This product is the extension cable only. Please check the Bently Nevada datasheet or contact us for compatible connectors and accessories.
• Q: How do I ensure I'm buying an original Bently Nevada part?
  A: We guarantee that all our parts, including the 330930-060-01-00, are 100% original and new, sourced through authorized channels to ensure performance and warranty validity.

For detailed installation drawings and full system specifications, we recommend downloading the official datasheet. Download the 3300 XL NSv Proximity Transducer System Datasheet (147385) here.
