Allen-Bradley 1769-OF4 Compact I/O Analog Output Module

Allen-Bradley 1769-OF4 Compact Analog Output Module Overview

Key Technical Specifications

• Brand: Allen-Bradley
• Catalog Number: 1769-OF4 (Series A and B compatible)
• Output Channels: Four (4) single-ended, individually configurable
• Analog Ranges: Voltage: ±10V, 0-10V, 0-5V, 1-5V dc; Current: 0-20 mA, 4-20 mA
• Resolution: 15 bits plus sign (unipolar and bipolar)
• Conversion Rate: 2.5 ms per module
• Accuracy: 0.5% full scale at 25 degrees Celsius
• Power Draw: 120 mA @ 5.1V dc; 170 mA @ 24V dc
• Heat Dissipation: 2.86 W
• Wire Size: 22-14 AWG solid, 22-16 AWG stranded
• Dimensions (Module): 118 x 35 x 87 mm (4.65 x 1.38 x 3.43 inches)
• Weight (Module): 280 g (0.61 pounds)

Frequently Asked Questions (FAQ)

• What is the condition of the 1769-OF4 module you sell?
  We supply only brand new, genuine Allen-Bradley 1769-OF4 modules. Each unit comes in original packaging with full manufacturer specifications.
• Do you have the 1769-OF4 in stock?
  Yes, we maintain ample inventory of the 1769-OF4 analog output module. Stock levels are regularly updated to ensure we can fulfill orders promptly.
• How quickly can you ship the 1769-OF4?
  We process and dispatch orders within five working days after payment confirmation. Our efficient logistics team ensures your order leaves our facility without delay.
• Which shipping carriers do you use?
  We ship exclusively through trusted international carriers including FedEx, UPS, and DHL. This ensures reliable and traceable delivery to your location worldwide.
• What is your return policy for this module?
  We offer a 30-day return window for the 1769-OF4 module. Items must remain in their original, unopened condition to qualify for a full refund.
• Does the 1769-OF4 require calibration before use?
  No, the hardware design of this 1769-OF4 guarantees accuracy without field calibration. You can install and configure it immediately within your system.
• Can I mix voltage and current outputs on different channels?
  Yes, each of the four channels on the 1769-OF4 operates independently. You can configure one channel for 4-20 mA current and another for 0-10V dc voltage as needed.
• What controllers are compatible with this module?
  The 1769-OF4 works with MicroLogix 1500 and CompactLogix controllers. Check your controller's power supply distance rating to ensure proper integration.
