3500/94M-03-00-00 | Bently Nevada VGA Module

Bently Nevada 3500/94M-03-00-00 VGA Display – 10" Panel Mount System Display

• Manufacturer: Bently Nevada – industry leader in protection monitoring.
• Part Number: 3500/94M-03-00-00 – System Display, VGA type.
• Model: VGA Display with 10" screen size.
• Condition: New & Original in factory packing. Full 12 months factory warranty.
• Display Size & Mounting: 03 = 10" Display, Panel Mount (includes installation hardware).
• KVM Extender & Router Box Cables: 00 = None.
• Agency Approval Option: 00 = None (base model).

Key Technical Specifications

• Power Consumption (VGA Display Unit): 4.6 watts maximum – very energy efficient.
• High-speed network: Monitors status, data, and values from the 3500 system.
• RS232 port (I/O): Handles touch controller data for interactive operation.
• OK LED: Indicates proper operation of the 3500/94M-03-00-00 module.
• TX/RX LED: Shows communications between other system modules.
• VGA port (I/O): Transmits analog red, green, blue, and sync signals to the display.
• Front Port: Provides 24 Vdc power out, VGA signal out, and touch commands in.

Environmental Limits & Certifications

• Operating Temperature: -20°C to 65°C (-22°F to 149°F).
• Storage Temperature: -40°C to 85°C (-40°F to 185°F).
• Humidity: 95% non-condensing for reliable industrial use.
• FCC Compliance: Part 15 – device may not cause harmful interference and must accept any interference received.
• EMC Standards: EN 61000-6-2 and EN 61000-6-4. Directive 2014/30/EU.
• Electrical Safety: CSA C22.2 61010-1, UL EN 61010-1, Directive 2014/35/EU.
• RoHS Directive: 2011/65/EU compliant.

Physical Characteristics & Rack Space

• 3500/94M VGA Display Module Dimensions: 241.3 mm x 24.4 mm x 241.8 mm (9.5 in x 0.96 in x 9.52 in). Weight: 0.73 kg (1.6 lb).
• I/O Module Dimensions: 241.3 mm x 24.4 mm x 99.1 mm (9.50 in x 0.96 in x 3.90 in). Weight: 0.34 kg (0.75 lb).
• Monitor Module Rack Space: 1 full-height front slot.
• I/O Module Rack Space: 1 full-height rear slot.
• 10" Advantech Display (ANA-D3510-100-A1): 249 mm x 389 mm x 48 mm (9.8 in x 15.3 in x 1.9 in). Touch screen diagonal: 267 mm (10.5 in). Weight: 4.0 kg (8.78 lb).

Display Monitor Specifications (Advantech 10")

• Screen Size: 10" diagonal. Type: LCD with LED back light – industrial hardened.
• Mounting Styles: Face Mount, 19" Rack Mount, Panel Mount, or Independent Mount.
• Power Input: 24 Vdc supply included (permissible range 10 Vdc to 28 Vdc). Inrush current: 3.5 A @ 24 V (< 500 µs). Operating current: < 500 mA.
• Agencies: CE, UL, CUL certified. IP54 designed for dust and water spray protection.
• Hazardous Area Approvals: Class I, Div 2 and ATEX/IECEx certified.
• Temperature Rating: -20°C to 65°C (-4°F to 149°F). For temperatures below -20°C, a heated enclosure is required.
• Humidity: 10% to 85% RH non-condensing.
• Touch Interface: GFG Resistive Touch Screen from Advantech.
• Warranty: One year recommended for industrial use.

Frequently Asked Questions (FAQ)

• Q: Is the 3500/94M-03-00-00 brand new original?
  A: Yes, we supply 100% brand new original Bently Nevada units in factory packing. No used or counterfeit items.
• Q: How quickly will you ship my order?
  A: We dispatch all orders within 5 business days after payment confirmation.
• Q: Which carriers do you use for international shipping?
  A: We typically use DHL, FedEx, and UPS – fast and reliable door-to-door delivery.
• Q: What is your return policy?
  A: We support 30 days return from delivery date. Items must be unused and in original packaging.
• Q: Does the display work without the 3500/22 TDI module?
  A: No, the 3500/94M-03-00-00 requires a 3500/22 TDI module for proper operation.
• Q: What is the minimum operating temperature for the touch screen?
  A: The screen works from -20°C to 65°C. Below -20°C, you need a heated enclosure.
• Q: Is this display certified for hazardous locations?
  A: Yes, the Advantech display includes Class I Div 2 and ATEX/IECEx certification.
• Q: What firmware version does the 3500/94M need?
  A: It requires firmware 4.06 Rev. C or newer. Check compatibility with your TDI module.
