330904-08-10-05-12-05 New NSv Proximity Probes Bently Nevada

Bently Nevada 330904-08-10-05-12-05 | 3300 NSv Proximity Probe

Model Code Breakdown

• Brand: Bently Nevada
• Model Series: 3300 XL NSv
• Full Suffix Details for 330904-08-10-05-12-05:
  • 330904 – Armored 3300 NSv probe with M8x1 thread.
  • 08 – 80 mm unthreaded probe length.
  • 10 – 100 mm total stainless steel case length.
  • 05 – Integrated 0.5 meter cable length.
  • 12 – ClickLoc connector with FluidLoc cable seal.
  • 05 – Certified with CSA, ATEX, and IECEx approvals.

Technical Specifications & Performance

• Brand & Model: Bently Nevada 330904-08-10-05-12-05
• Measurement Range: 0.25 to 1.75 mm (10 to 70 mils).
• Scale Factor / Sensitivity: 7.87 V/mm with a ±20% tolerance.
• Linearity & Accuracy: Maximum error of ±0.06 mm.
• Frequency Response: DC to 10 kHz bandwidth.
• Wiring Distance: Maintains signal up to 305 meters.
• Operating Temperature: -52°C to +177°C reliable range.
• Environmental Tolerance: Armored design resists harsh industrial conditions.
• Interference Resistance: Shielded for stable signal output.

Robust Materials & Build

• Probe Tip Material: Durable Polyphenylene Sulfide (PPS).
• Probe Case: Constructed from AISI 304 stainless steel.
• Integrated Cable: 75 ohm, FEP insulated, 0.5 meter long.
• Minimum Bend Radius: 25.4 mm for safe cable routing.

Frequently Asked Questions (FAQ)

• Q: Is this a genuine Bently Nevada part?
  A: Absolutely. We supply only 100% new and original Bently Nevada products.
• Q: Do you have this model in stock?
  A: Yes, we maintain stock for fast delivery, typically shipping within 5 days.
• Q: What are my shipping options?
  A: We use reliable services including DHL, FedEx, and UPS for worldwide delivery.
• Q: What is your return policy?
  A: We offer a straightforward 30-day return policy for qualifying items.
• Q: What is the main advantage of this NSv probe?
  A: It provides armored protection and modern performance as a direct upgrade for older RAM probes.
• Q: What is the cable length and connector type?
  A: It features a 0.5-meter fixed cable with a secure ClickLoc connector.

For complete wiring diagrams, mounting details, and system specifications, download the official datasheet. Download the 3300 XL NSv Proximity Transducer System Datasheet PDF here.
