330901-22-12-10-11-05 3300 XL NSv Bently Nevada Proximity Probe

3300 XL NSv Proximity Transducer 330901-22-12-10-11-05 System Overview

Key Mechanical Specifications

• We machine the probe body with a 7/8‑28 UNF thread and recommend a maximum engagement of 0.375 in for proper installation.
• An 8 mm probe tip diameter optimises target sensitivity, ensuring consistent eddy‑current performance.
• We construct the housing from AISI 304 stainless steel for excellent corrosion resistance and mechanical strength.
• The tip material uses high‑temperature Polyphenylene Sulfide (PPS) to withstand harsh process conditions.
• We equip the probe with a miniature coaxial ClickLoc connector and FluidLoc FEP cable for reliable, oil‑resistant connections.
• Cable impedance measures 75 Ω ±2% with a typical capacitance of 100 pF/m to maintain signal integrity.
• Total cable length comes as 1.0 m (39 in), ready to interface with extension cables or proximitors.
• Probe weight approximates 50 g/m (0.14 oz/in), making it lightweight yet robust for mounting.

Electrical Characteristics & Performance

• We guarantee a DC resistance of 4.2 Ω ±0.5 Ω from centre to outer conductor (tested at 1 metre).
• Dielectric strength exceeds 1500 Vrms for 60 seconds, ensuring safe operation in high‑voltage environments.
• Signal rise time is typically 2 ns, allowing accurate capture of fast vibration transients.
• EMI shielding provides attenuation ≥80 dB at 1 MHz, rejecting electrical interference in industrial settings.
• We manufacture the probe under strict quality controls and hold UL, CE, and RoHS approvals.
• Bently Nevada backs this 3300 XL NSv with a 1‑year warranty against defects in material and workmanship.

Environmental Durability & Ratings

• We qualify the 3300 XL NSv for an operating and storage temperature range of -52 °C to +177 °C.
• A Viton O‑ring provides differential pressure sealing up to 500 psi, suitable for high‑pressure casings.
• Minimum cable bend radius is 10 mm; exceeding this may impair signal quality.
• We rate the ClickLoc connector for 500 mating cycles; recommended installation torque is 5.1 N·m (rated max 7.3 N·m).
• The FEP shield jacket exhibits tensile strength >18 MPa, resisting damage during installation.

Download the detailed 3300 XL NSv datasheet: 3300 XL NSv Proximity Transducer System Datasheet – 147385 (PDF).
