330901-00-50-05-02-00 3300 NSv Proximity Sensor Bently Nevada

330901-00-50-05-02-00 Bently Nevada 3300 NSv Proximity Probe Datasheet

Detailed Model Configuration and Materials

• Base Model 330901: This represents a 3300 NSv probe with standard 1/4-28 UNF mounting threads and no armor. It includes zero unthreaded length (00) for a direct, secure fit into the mounting hole.
• Physical Dimensions: The 330901-00-50-05-02-00 features a 5.0-inch case length (50) for extended reach. Its total length (05) is 0.5 meters, making it ideal for close-coupled transducer system setups.
• Connector Type: This model uses a mini coaxial ClickLoc connector with a standard cable (02). It integrates a 75 Ohm FEP-insulated cable for consistent high-frequency signal transmission.
• Material Construction: The probe case utilizes AISI 304 stainless steel for excellent corrosion resistance. The probe tip employs high-temperature PPS plastic, capable of withstanding up to 177°C.

Technical Specifications and Performance Stats

• Electrical Characteristics: The 330901-00-50-05-02-00 exhibits a DC resistance of 4.0 ± 0.5 ohms. It provides a sensitivity of 7.87 V/mm for clear, accurate vibration signals.
• Mechanical Limits: Maximum recommended installation torque is 7.3 N·m, with a safe suggested torque of 5.1 N·m. Maximum thread engagement should not exceed 0.375 inches for proper fit.
• Environmental Tolerance: This 3300 NSv probe operates from -52°C to 177°C. It includes a Viton O-ring seal that accommodates pressure differences. Avoid prolonged exposure below -34°C to protect the seal.
• Weight Range: The probe weighs between 14 and 150 grams, depending on cable length. This lightweight design simplifies installation and reduces mechanical stress.

Frequently Asked Questions (FAQ)

• What is the exact model number for this probe?
  The specific model is 330901-00-50-05-02-00, a Bently Nevada 3300 NSv series probe with a 5-inch case and 0.5m cable.
• What are the key specifications of the 330901-00-50-05-02-00 ?
  This 3300 NSv probe features a 5.0-inch case, 7.87 V/mm sensitivity, and a Viton O-ring seal. It operates from -52°C to 177°C.
• What materials does Bently Nevada use for this probe?
  The 330901-00-50-05-02-00 uses an AISI 304 stainless steel case and a PPS tip. The cable features FEP insulation for durability.
• Do you have the 330901-00-50-05-02-00 in stock?
  Yes, we have this model in stock as a new and authentic unit. We maintain inventory for the Bently Nevada 3300 NSv series.
• How quickly can you ship the 330901-00-50-05-02-00 ?
  We typically dispatch orders within 5 days. We ship globally using FedEx, UPS, and DHL for reliable delivery.
• What is your return policy for this proximity probe?
  We accept returns on this new item within 30 days of receipt, provided it remains in its original condition.
• What is the temperature limit for this probe?
  The 330901-00-50-05-02-00 operates from -52°C to 177°C. Avoid prolonged exposure below -34°C to protect the Viton seal.
• Where can I download the datasheet?
  You can download the full product datasheet for the 3300 XL NSv system here: 3300 XL NSv Proximity Transducer System Datasheet - 147385. Please review this document for detailed specifications.
