330901-00-16-05-02-CN Bently Nevada 3300 NSv Proximity Probe

330901-00-16-05-02-CN 3300 NSv Proximity Probes

Model Code Breakdown

• 330901: Base 3300 NSv Probe with 1/4-28 UNF thread, no armor
• 00: Unthreaded length measures 0.0 inches for straightforward installation
• 16: Overall case length stands at 1.6 inches, fitting tight machine locations
• 05: Total probe length equals 0.5 meters (20 inches) from tip to connector
• 02: Connector type features Mini coaxial ClickLoc with standard cable
• CN: Country-specific approval included for regional compliance

Key Features

• Materials: Case uses AISI 304 stainless steel for excellent rust and wear resistance; tip employs Polyphenylene sulfide (PPS) operating safely up to 177°C; cable is 75Ω coaxial with FEP insulation (available in 0.5m, 1m, 5m, or 7m lengths; cable diameter 3mm)
• Electrical Specs: DC resistance for 0.5m length measures 4.0 ± 0.5 ohms from center to outer conductor; frequency response covers 0-10 kHz capturing fast machine changes; sensitivity delivers 200 mV/mil for clear, accurate signals
• Durability: Maximum torque reaches 7.3 N·m (65 in·lb); suggested torque is 5.1 N·m (45 in·lb) for optimal performance; thread fits up to 0.375 inches (1/4-28 thread); weight ranges from 14-150g (0.5-5.3 oz) keeping installation simple
• Environment: Temperature range spans -52°C to 177°C (-62°F to 351°F) for hot and cold locations; pressure seal uses Viton O-ring handling pressure differences between tip and case; staying below -34°C (-30°F) for long periods may damage the seal

Frequently Asked Questions

• Is the 330901-00-16-05-02-CN probe brand new?
  All probes are brand new and original from Bently Nevada, sealed in factory anti-static packaging.
• What is the delivery time for this 3300 NSv probe?
  We maintain stock of this model. We ship within 5 working days after receiving your order.
• Which shipping carriers do you use?
  We ship via FedEx, UPS, or DHL based on your preference at checkout.
• Can I return this probe within 30 days?
  Yes, we offer a 30-day return policy for unused items in original condition.
• What does the CN approval mean?
  The CN suffix indicates country-specific certifications included, making this probe compliant with regional industrial standards.
• What is the minimum temperature limit?
  The probe operates from -52°C up to 177°C, but avoid prolonged exposure below -34°C to protect the Viton seal.
• Does this probe work with existing 3300 XL systems?
  Yes, the 330901-00-16-05-02-CN integrates seamlessly with all 3300 XL NSv monitors and extension cables.

For complete electrical, mechanical, and installation specifications, download the official 3300 XL NSv Proximity Transducer System Datasheet. This document contains full system details and performance curves.

Download PDF: 3300 XL NSv Datasheet – 147385
