330876-01-10-01-05 3300 XL 50 mm Sensor - Bently Nevada Proximity Probe

330876-01-10-01-05 3300 XL 50 mm Proximity Probe | Bently Nevada Precision Sensor

• Brand & Model: Bently Nevada 330876-01-10-01-05 – 3300 XL 50 mm Proximity Probe. This model includes suffix codes for thread, length, cable type, and approvals.
• Case Diameter & Tip Material: The overall case diameter measures 1.99 inches (50 mm) at the sensor face. The probe tip uses Polyphenylene Sulfide (PPS) plastic. The stainless steel case is AISI 304 SST for durability.
• Cable Specifications: The probe features a High-Temperature FluidLoc cable with armor. Cable outer diameter is 4.8 mm per 75 Ω PFA-insulated triaxial FluidLoc specification. The 330876 includes ClickLoc connectors with a removable collar for tight routing.

Technical Specifications – Core Parameters

• Sensing Diameter: 50 mm (1.97 inches) – this matches the probe face size for proximity measurements.
• Electrical Resistance (1.0 m probe): 6.4 ± 0.5 Ω from center conductor to coaxial shield. This ensures consistent signal quality.
• Operating Temperature Range: -35 °C to +200 °C (-31 °F to +392 °F). The probe withstands short-term peaks up to +250 °C (482 °F) for a maximum of 24 hours.
• Thread Type: ¼-20 UNF thread with a maximum engagement of 0.750 inches. This thread allows easy mounting in standard probe holders.
• Total Length Option: Suffix -10 indicates a total length of 1.0 meter (3.3 feet). Other lengths available upon request.
• Agency Approvals: Suffix -05 provides multiple agency approvals for global industrial use.

Frequently Asked Questions (FAQ)

• Is the 330876-01-10-01-05 probe brand new and original? Yes, we only supply genuine Bently Nevada 330876-01-10-01-05 probes. Every unit is factory-fresh and original.
• What is the maximum cable length for this probe? This specific suffix (-10) provides 1.0 meter total length. We can advise other lengths on request.
• Can I use this probe in high-humidity areas? Absolutely. The dual seals and FluidLoc cable prevent moisture ingress, making it perfect for humid or wet environments.
• Do you have stock available for immediate shipment? Yes, we have ample stock. We can ship your order within 5 days using DHL, UPS, or FedEx.
• What is the return policy for this probe? We support 30-day returns from the delivery date. Items must remain unused and in original packaging.
• Does the probe work with existing 3300 XL monitoring systems? Yes, the 330876 fully integrates with Bently Nevada 3300 XL proximity transducer systems.

Download the full datasheet: 3300 XL 50 mm Proximity Transducer System Datasheet (PDF) – get complete technical curves and installation drawings.

Contact Information Inquiries: sales@nex-auto.com or +86 153 9242 9628 (WhatsApp).

Partner: NexAuto Technology Limited
