330708-00-10-90-12-05 Bently Nevada 11mm Proximity Probe

Bently Nevada 330708-00-10-90-12-05 3300 XL 11 mm Proximity Probe

• Brand & Model: Bently Nevada 330708-00-10-90-12-05 from the 3300 XL 11 mm Proximity Transducer System series.
• Tip Material: Polyphenylene sulfide (PPS). Case Material: 304 stainless steel.
• Cable: 9.0 m (29.5 ft) of 75 Ω triaxial FEP with FluidLoc. Connector: ClickLoc coaxial with cover.
• Temperature Range: –51°C to +177°C. Accuracy: ±2%. Frequency response: DC to 10 kHz.
• Resistance: 5.9 ± 0.5 Ω (at 1 m). Signal-to-noise ratio: 60 dB.
• Cable capacitance: 95 pF/m. Max pressure: 12 bar. Vibration tolerance: 20 g rms.
• Approvals: Multiple agencies. Torque: Max 45.2 N·m. Recommended torque: 15.2 N·m.
• Bend radius: 25 mm (1 in). Weight: 0.35 kg.

Frequently Asked Questions (FAQ)

• Q: Is the Bently Nevada 330708-00-10-90-12-05 brand new and original?
  A: Yes, we only supply brand new and original Bently Nevada probes.
• Q: Do you have this model in stock?
  A: Yes, we have the 330708-00-10-90-12-05 in stock for quick dispatch.
• Q: How long does delivery take?
  A: We dispatch within 5 days. Shipping uses FedEx, UPS, or DHL for fast delivery.
• Q: What is the frequency response of this probe?
  A: The probe responds from DC to 10 kHz with ±2% accuracy.
• Q: What is the signal-to-noise ratio?
  A: It provides a 60 dB signal-to-noise ratio for clean measurements.
• Q: What is the maximum pressure rating?
  A: The probe handles up to 12 bar of pressure.
• Q: Can I return the product?
  A: Yes, we support returns within 30 days from the delivery date.
• Q: Where can I download the full datasheet?
  A: You can download the PDF below for complete technical specifications.

Download the official datasheet here: 3300 XL 11 mm Proximity Transducer System Datasheet (PDF). This file contains detailed resistance, torque, frequency, and pressure data.
