330708-00-10-90-01-00 Bently Nevada - Proximity Sensor

Bently Nevada 3300 XL 11 mm Proximity Probe Overview

Key Features and Performance

• Brand: Bently Nevada
• Model: 330708-00-10-90-01-00
• Tip Material: Polyphenylene sulfide (PPS)
• Case Material: AISI 304 stainless steel
• Cable Type: 75Ω triaxial FEP insulated
• Cable Length: 9.0 meters (29.5 feet)
• Connector: ClickLoc miniature coax with protector
• Frequency Band: 1 Hz to 22 kHz (±3 dB)
• Amplitude Range: 0.02 mm to 3.0 mm (1 mil to 118 mil)
• Response Time: 0.1 ms over 9 meter cable runs
• Shock Rating: 100 g for 11 ms pulse
• Tensile Strength: Cable rated to 150 N pull force
• Dielectric Strength: 1000 Vrms at 60 Hz
• Seal Rating: Differential pressure up to 20 bar
• MTBF: ≥60,000 hours at 25°C
• Operating Temperature: -52°C to +177°C
• Storage Temperature: -52°C to +177°C
• DC Resistance: 5.9 Ω ± 0.5 Ω per 1 meter

Frequently Asked Questions (FAQ)

• Is this a brand new original part?
  Yes, we supply only brand new and original Bently Nevada components.
• Do you have the 330708-00-10-90-01-00 in stock?
  Yes, we have this exact model in stock and ready to ship.
• How fast can you ship this probe?
  We ship all orders within 5 business days after payment confirmation.
• Which shipping carriers do you use?
  We use FedEx, UPS, and DHL for global deliveries.
• What is your return policy?
  We support returns within 30 days from the delivery date.
• Does this probe work with the 3300 XL system?
  Absolutely, this probe integrates directly with the Bently Nevada 3300 XL proximity transducer system.
• What is the frequency response of this probe?
  This probe responds accurately from 1 Hz to 22 kHz.
• What is the maximum seal pressure?
  The probe handles differential pressure up to 20 bar.
• What is the expected MTBF?
  The probe has an MTBF of 60,000 hours at 25°C.

Download the official datasheet for complete technical details: 3300 XL 11 mm Proximity Transducer System Datasheet (PDF).
