330425-02-CN Transducers Bently Nevada

Bently Nevada 330425-02-CN Accelerometer Transducer

Key Technical Specifications

• Sensitivity: 10.2 mV/m/s² (100 mV/g) ±5%
• Acceleration Range: 490 m/s² (50 g) peak within 10 Hz–15 kHz
• Frequency Response: 10 Hz to 15 kHz (±3 dB)
• Amplitude Linearity: ±1% up to 490 m/s² (50 g) peak
• Broadband Noise Floor: 0.039 m/s² (0.004 g) rms

Environmental and Durability Features

• Operating Temperature: -55°C to +121°C (-67°F to +250°F)
• Shock Survivability: 49,050 m/s² (5000 g) peak
• IP Rating: Equivalent to IP68 (dust tight and watertight)
• Case Material: 316L stainless steel for maximum corrosion resistance
• Mounting: M8 x 1 integral stud with 4.1 N·m (3.0 ft·lb) torque

Electrical and Physical Properties

• Input Voltage: -24 ± 0.5 Vdc
• Bias Current: 2 mA nominal
• Output Bias Voltage: -8.5 ± 0.5 Vdc
• Weight: 99 g (3.5 oz) without cable
• Dimensions: 23 mm diameter × 59 mm height including stud

Frequently Asked Questions (FAQ)

• Is the Bently Nevada 330425-02-CN accelerometer new and in stock?
  Yes, we supply only brand new, original units, and we currently have them in stock.
• Can this sensor operate in extreme temperatures?
  Yes, it operates from -55°C to +121°C with stable performance.
