330104-00-07-05-02-00 Bently Nevada Proximity Probe 3300 XL

Bently Nevada 330104-00-07-05-02-00 3300 XL 8 mm Proximity Probe

• Brand & Model: Bently Nevada 330104-00-07-05-02-00, 3300 XL 8 mm Proximity Probe.
• Unthreaded Length: 0 mm (standard configuration).
• Overall Case Length: 70 mm for flexible mounting options.
• Total Cable Length: 0.5 meter (1.6 feet) with standard cable.
• Connector Type: Miniature coaxial ClickLoc connector for secure signal transmission.
• Agency Approval: Not required for this standard version (00 option).

Technical Specifications

• Linear Range: 2 mm (80 mils); starts from 0.25 mm (10 mils) up to 2.3 mm (90 mils).
• Output Voltage Range: Approximately –1 to –17 Vdc over the linear range.
• Recommended Gap (Radial Vibration): -9 Vdc, roughly 1.27 mm (50 mils).
• Probe DC Resistance (0.5m): 7.45 ± 0.50 Ω (center to outer conductor).
• Maximum Case Torque: 33.9 N•m (300 in•lbf); recommended 11.2 N•m (100 in•lbf).
• Probe Temperature (Standard): -52°C to +177°C (-62°F to +350°F).
• Extended Temperature Tip: -52°C to +218°C (-62°F to +425°F).
• Cable & Connector Temp (Extended): -51°C to +260°C (-60°F to +500°F).
• Humidity Tolerance: Less than 3% change in ASF after 56 days at 93% RH (IEC 68-2-3).
• Probe Weight: 323 g/m (11.4 oz) for the probe assembly.

Installation & Field Wiring

• Field Wiring: Use 0.2 to 1.5 mm² (16 to 24 AWG) shielded triad cable.
• Maximum Cable Length: 305 meters (1,000 feet) between probe and monitor.
• Probe Case Thread: M10x1 with 15 mm maximum thread engagement.
• Sealing Material: Viton® O-ring for differential pressure sealing.
• Pressure Test: Not tested before shipment; contact custom design if needed.
• Recommended Torque: 11.2 N•m (100 in•lbf) for standard forward mounted probes.

Environmental & Certifications

• Intrinsic Safety (ia): Ex ia IIC T5…T1 Ga; Class I, Groups A-D; Class II, Groups E-G.
• Non-incendive (nA/ec): Ex nA IIC T5…T1 Gc; Class I, Div 2, Groups A-D.
• Operating Humidity: Passes 93% humidity test for 56 days per IEC standard.
• Probe Tip Material: Polyphenylene sulfide (PPS) for durability.
• Probe Case Material: AISI 303 or 304 stainless steel (SST).

Package Contents

• 1 x 330104-00-07-05-02-00 3300 XL 8 mm Probe with armor.
• 1 x Miniature coaxial ClickLoc connector (standard cable).
• Mounting hardware and O-ring seal.
• Installation guide (quick start).
• No certificates or warranty documents included.

Shipping & Delivery

• We ship via FedEx, UPS, or DHL (express service).
• Delivery within 5 business days after order confirmation.
• All items are brand new and original from Bently Nevada.
• We maintain stock for immediate dispatch.

Frequently Asked Questions (FAQ)

• Is this probe brand new? Yes, we supply only brand new and original Bently Nevada parts.
• What is the linear range of the 330104-00-07-05-02-00? Its linear range is 2 mm (80 mils) from 0.25 mm to 2.3 mm.
• What cable length does this model have? The total cable length is 0.5 meter (1.6 feet) with a ClickLoc connector.
• Can I use this probe in high humidity? Yes, it withstands 93% humidity for 56 days with minimal scale factor change.
• What is the recommended gap for radial vibration? Set the gap to -9 Vdc, which equals about 1.27 mm (50 mils).
• Do you have stock? Yes, we have these probes in stock and ship within 5 days.
• What shipping methods do you offer? We ship using FedEx, UPS, or DHL for fast and reliable delivery.
• Can I return the probe? Yes, we support a 30-day return policy for unused items.
• Is this probe intrinsically safe? Yes, it meets Ex ia IIC T5…T1 Ga and Class I, Div 2 requirements.
• What is the probe case material? The case is AISI 303 or 304 stainless steel for durability.
