Bently Nevada 3300 XL 8 mm Proximity Probe – Model 330102-04-45-50-01-00

Key Technical Specifications

• Brand & Model: Bently Nevada 330102-04-45-50-01-00 (3300 XL series).
• Probe Type: 8 mm proximity probe with 3/8-24 UNF thread and armor.
• Unthreaded Length: 0.4 inches (option 04).
• Overall Case Length: 4.5 inches (option 45).
• Total Length: 5.0 meters (16.4 feet) – option 50.
• Connector and Cable Type: Miniature coaxial ClickLoc connector with connector protector and standard cable (option 01).
• Agency Approval: None required (option 00).
• Nominal DC Resistance (RPROBE): 8.73 ± 0.50 Ω for 5.0 meter length.
• Probe Tip Material: Polyphenylene sulfide (PPS).
• Probe Case Material: AISI 303 or 304 stainless steel (SST).
• Maximum Thread Engagement Length: 0.563 inches for 3/8-24 thread.
• Linear Range: 2 mm (80 mils) from approximately 0.25 mm to 2.3 mm (10 to 90 mils) corresponding to –1 to –17 Vdc.
• Recommended Gap Setting for Radial Vibration: -9 Vdc [approximately 1.27 mm (50 mils)].
• Probe Weight: 323 g/m (11.4 oz).
• Operating & Storage Temperature (Standard Probe): -52°C to +177°C (-62°F to +350°F).
• Extended Temperature Range Tip: -52°C to +218°C (-62°F to +425°F).
• Extended Temperature Cable & Connector: -51°C to +260°C (-60°F to +500°F).
• Pressure Seal Caution: Exposing the probe below -34°C (-30°F) may cause premature seal failure.
• Relative Humidity Performance: Less than 3% change in Average Scale Factor (ASF) after 56 days at 93% humidity per IEC 68-2-3.
• Compatibility Note: This 5-meter probe works exclusively with the 5 meter Proximitor sensor.

Field Wiring Specifications

• Wire Size: 0.2 to 1.5 mm² (16 to 24 AWG).
• Cable Recommendation: Use 3-conductor shielded triad cable with tinned field wiring.
• Maximum Field Wiring Length: 305 meters (1,000 feet) between the 3300 XL Proximitor Sensor and the monitor.
• Frequency Response: See Figures 10 and 12 for signal roll-off at high frequencies when using longer field wiring lengths.

Hazardous Area Approvals

• ia (Intrinsic Safety): Class I, Zone 0 AEx/Ex ia IIC T5...T1 Ga when installed with zener barriers (drawing 141092) or galvanic isolators. Also covers Class I Groups A-D, Class II Groups E-G, and Class III.
• nA / ec (Nonincendive): Class I, Zone 2 AEx/Ex nA IIC T5…T1 Gc and Class I Division 2 Groups A-D when installed per drawing 140979.

Frequently Asked Questions (FAQ)

• Is this probe a genuine new unit? Yes, we supply this 330102-04-45-50-01-00 as a brand new, original Bently Nevada component.
• Do you have stock available? Yes, we have this probe in stock for immediate orders.
• What is your shipping time? We dispatch all orders within 5 business days after payment confirmation.
• Which carriers do you use? We ship via FedEx, UPS, or DHL for reliable worldwide delivery.
• Can I return this product? Yes, we accept returns within 30 days of receipt, provided the item is unused.
• What is the recommended gap setting for vibration measurements? Set the probe to -9 Vdc, which equals approximately 1.27 mm (50 mils) from the target.
• What is the linear range of this probe? The linear range spans 2 mm (80 mils) from 0.25 mm to 2.3 mm (10 to 90 mils).
• Which Proximitor sensor works with this 5-meter probe? This 5-meter probe works exclusively with the 5 meter Proximitor sensor.
• What type of connector does this probe use? It uses a miniature coaxial ClickLoc connector with a connector protector and standard cable.
