2711P-T15C4D8 PanelView Plus 6 1500 Touch HMI Allen-Bradley

2711P-T15C4D8 PanelView Plus 6 1500 Operator Terminal

Technical Specifications

• Manufacturer – Allen‑Bradley
• Model Number – 2711P-T15C4D8
• Product Family – PanelView Plus 6 Operator Terminals
• Series – PanelView Plus 6 1500
• Display Size – 15.0 inches diagonal
• Display Area – 304 x 228 mm (12.0 x 9.0 in.)
• Resolution – 1024 x 768 pixels, 18‑bit color
• Backlight – CCFL, 50,000 hours min at 25 °C, field replaceable
• Touch Lifespan – 1 million presses
• Memory – 512 MB Flash / 512 MB RAM
• Input Voltage – 18‑30 VDC (nominal), 18‑32 VDC range
• Communication – Ethernet, RS‑232, 2 x USB host
• Enclosure Rating – NEMA/UL Type 12, 13, 4X; IEC IP54, IP65
• Shipping Weight – 13 lbs (approx.)
• Shipping Dimensions – 20 x 14 x 8 inches

Frequently Asked Questions

• What is the touchscreen lifespan?
  The resistive touch supports 1 million presses, and the backlight lasts 50,000 hours minimum.
• Can I use this terminal outdoors?
  It is rated NEMA 4X and IP65 for indoor use only, not for direct outdoor exposure.
• What communication protocols does the Ethernet port support?
  It supports EtherNet/IP for controller communication, application transfers, and printing.
• Does the package include a memory card or software?
  It includes the terminal and accessories listed; application software is not provided.
• What is your return policy?
  We accept returns within 30 days of delivery – contact us for a return authorization.
• How long until my order ships?
  We ship within 5 business days after order confirmation.
