2711P-K6C1D PanelView Plus 600 Color Terminal Keypad Allen-Bradley

Allen-Bradley 2711P-K6C1D PanelView Plus 600 Color Terminal

Key Technical Specifications

• Brand and Model: Allen-Bradley 2711P-K6C1D belongs to the PanelView Plus 600 series.
• Display Type: Features a color active matrix TFT display with 320 x 240 pixel resolution and 18-bit color graphics.
• Display Area: Measures 111 x 84 mm (4.37 x 3.3 in.) for clear process visualization.
• Display Luminance: Provides 300 cd/m² (Nits) brightness for excellent visibility.
• Backlight: Uses a CCFL backlight with a 50,000 hour half-life. This backlight is not replaceable.
• Keypad: Includes 10 function keys (F1 to F10), numerical keys, and navigation keys. Features stainless steel specialized keypads with 340 g operational shock withstand rating.
• Internal Memory: Provides 64 MB non-expandable flash memory with 20 MB available for application storage.
• External Storage: Supports 256 MB CompactFlash card for external memory storage.
• Communication Ports: Embeds one Ethernet port, one RS-232 port, one Remote I/O (RIO) port, and one USB port.
• Input Power: Accepts a DC supply range of 10-30 VDC (nominal 24 VDC). Power consumption is 24 W at 1 A and 24 VDC.
• Real-Time Clock: Includes a battery-backed clock with ±2 minutes per month accuracy and 5 years battery life at 25 °C.
• Operating Temperature: Functions reliably from 0 to 55 °C (32 to 131 °F).
• Humidity: Operates in 5 to 95% non-condensing relative humidity.

Frequently Asked Questions (FAQ)

• Do you have this model in stock?
  Yes, we maintain available inventory for the 2711P-K6C1D.
• What is the shipping time?
  We ship within 5 business days after order confirmation.
• Which carriers do you use for delivery?
  We ship via FedEx, UPS, and DHL for reliable global delivery.
• Can I return this product?
  Yes, we offer 30-day returns for the 2711P-K6C1D in original condition.
• What communication ports does this terminal have?
  The 2711P-K6C1D includes Ethernet, RS-232, Remote I/O (RIO), and USB ports.
• What is the display size and resolution?
  The terminal features a 5.7-inch color display with 320 x 240 pixel resolution and 18-bit color graphics.
• What is the backlight lifespan?
  The CCFL backlight has a 50,000 hour half-life.
• Can I expand the memory?
  Yes, the terminal supports 256 MB CompactFlash cards for external memory storage.
• What is the real-time clock battery life?
  The battery-backed clock provides 5 years of battery life at 25 °C.
