2711P-B12C4D9 Allen-Bradley PanelView Plus 6 HMI Touchscreen Keypad

Allen-Bradley PanelView Plus 6 Operator Terminal Overview

Technical Specifications

• Brand: Allen-Bradley
• Part Number: 2711P-B12C4D9 (Series A and Series B)
• Display Size: 12.1-inch color TFT display
• Input Type: Touchscreen and keypad dual control
• Communication: Ethernet (10/100Base-T, RJ45) and RS-232
• Input Power: 18-32 VDC
• Memory: 512 MB RAM
• Backlight Replacement: 2711P-RL12C2
• Communication Cable: 2711-NC14 (for RS-232)
• Shipping Weight: 10 lbs
• Shipping Dimensions: 20 x 14 x 8 in

Communication Features

• The built-in Ethernet port supports EtherNet/IP for real-time I/O messaging.
• This port handles application transfers, printing, and controller communication.
• The RS-232 port connects to legacy devices or serial printers.
• Users can add the 2711P-RN20 module for a second Ethernet port with a unique IP address.
• The Ethernet connector uses RJ45, 10/100Base-T with MDI/MDI-X auto-crossover support.

Installation Guidelines

• Mount the 2711P-B12C4D9 in a standard panel cutout with adequate ventilation.
• Provide a stable 18-32 VDC power supply and verify polarity before connection.
• Use shielded cables for RS-232 connections to reduce electrical noise interference.
• Secure the terminal using the included panel mounting clips.
• Ground the unit properly to ensure stable operation and safety compliance.

Environmental Specifications

• Operating temperature range: 0 to 55 °C (32 to 131 °F)
• Storage temperature: -25 to 70 °C (-13 to 158 °F)
• Humidity tolerance: 5% to 80% non-condensing
• Designed for harsh industrial environments with high noise immunity
• Backlight lifetime supports long-term operation; replacement part 2711P-RL12C2 available

Frequently Asked Questions

• Q: Is the 2711P-B12C4D9 a brand new original unit?
  A: Yes, we supply brand new original Allen-Bradley products with full factory specifications.
• Q: Do you have this model in stock?
  A: Yes, we have stock available for immediate orders.
• Q: What is the shipping lead time?
  A: We dispatch orders within 5 business days after payment confirmation.
• Q: Which shipping carriers do you use?
  A: We ship via FedEx, UPS, and DHL for fast worldwide delivery.
• Q: Does the 2711P-B12C4D9 support both touchscreen and keypad operation?
  A: Yes, this terminal features dual input with responsive touchscreen and a physical keypad.
• Q: What communication protocols does this terminal use?
  A: It supports EtherNet/IP and RS-232 serial communication.
• Q: Can I add an additional Ethernet port to the 2711P-B12C4D9?
  A: Yes, install the optional 2711P-RN20 communication module for a second Ethernet port.
• Q: What is your return policy?
  A: We offer a 30-day return window for items in original condition.
• Q: How much memory does the 2711P-B12C4D9 have?
  A: The unit includes 512 MB RAM for applications and data storage.
• Q: What power supply does this HMI require?
  A: It requires 18-32 VDC input power.
