24VDC Input Module GE Fanuc IC695MDL664

GE Fanuc IC695MDL664 RX3i 16-Point Smart Digital Input Module

Key Technical Specifications

• The IC695MDL664 operates at a rated voltage of 24 V DC for standard industrial use.
• It features 16 digital inputs organized in two isolated groups of eight points each.
• Each input requires only 12.2 mA of current for efficient power consumption.
• The module accepts a wide input voltage range from 18 to 32 V DC for flexible application.
• Power consumption measures 225 mA at 5V DC and 95 mA at 3.3V DC.

Design and Safety Features

• Group-to-group isolation provides 250 V AC / 1500 V AC protection for enhanced safety.
• The module includes 16 input LEDs plus S1 and S2 power indicators for clear status monitoring.
• It works seamlessly with limit switches, proximity sensors, and pushbuttons for versatile applications.
• The design supports both spring-style and box-style front terminal blocks for easy installation.
• You can install the module in any RX3i input or output slot without restrictions.

Frequently Asked Questions (FAQ)

• Is the IC695MDL664 module new and original?
  We supply only 100% brand new and authentic GE Fanuc modules with full manufacturer warranty.
• How many input points does this module have?
  The IC695MDL664 provides 16 digital input points divided into two isolated groups of eight.
• What is the operating voltage range?
  This module operates within a wide input voltage range of 18 to 32 V DC for application flexibility.
• What is your shipping policy?
  We process and ship all orders within 5 business days using DHL, FedEx, or UPS services.
• Do you accept returns?
  We offer a 30-day return policy for unused products in original packaging with all accessories.
• What devices can connect to these inputs?
  The inputs work perfectly with limit switches, proximity sensors, pushbuttons, and other standard field devices.
• Is isolation provided between input groups?
  Yes, the module provides 250 V AC / 1500 V AC isolation between the two groups of eight inputs.

For technical specifications and purchasing information, please contact: sales@nex-auto.com
