24V AC Input Module Schneider Electric 140DAI34000

Schneider Electric 140DAI34000 24V AC Discrete Input Module

Core Technical Specifications

• Brand: Schneider Electric
• Model: 140DAI34000
• Product Type: 24V AC Discrete Input Module
• Discrete Inputs: 16 channels (1 input word)
• Input Voltage: 24 Volts AC nominal
• Frequency Response: 47 to 63 Hertz
• ON State (Logic 1): 16-30V AC @60Hz / 18-30V AC @50Hz
• OFF State (Logic 0): 0-6V AC @60Hz / 0-5V AC @50Hz
• Input Current: ~12 mA (60Hz) / ~10.7 mA (50Hz)
• Response Time: 0.75-4.9ms (Off-On) / 7.3-12.3ms (On-Off)
• Isolation Rating: 1780 Vrms (channels and bus)

Environmental & Durability Ratings

• Operating Temperature: 0°C to 60°C (32°F to 140°F)
• Storage Temperature: -40°C to 85°C (-40°F to 185°F)
• Relative Humidity: Up to 95% (non-condensing)
• Operating Altitude: Up to 5000 meters (16404 ft)
• EMI/RFI Immunity: 10 V/m (80-2000 MHz)
• ESD Protection: 8 kV (air) / 4 kV (contact)
• Safety Certifications: cULus, FM Class 1 Div 2

Installation & Design Features

• LED Indicators: 16 green (input status), 1 green (Active), 1 red (Fault)
• Software Compatibility: Unity Pro, Concept, ProWORX 32
• Bus Current: 180 mA requirement
• Power Dissipation: 5.5 Watts maximum
• Module Format: Standard Quantum I/O size
• Input Protection: Withstands 30V continuous, 50V for 1 cycle surge

Frequently Asked Questions (FAQ)

• Is this module brand new and authentic? Yes, we supply only 100% new, genuine Schneider Electric products.
• What is your shipping time? We process and ship in-stock items within 5 business days.
• What voltage triggers an ON input? A solid ON signal requires 16-30V AC at 60Hz frequency.
• How many devices connect to this module? The 140DAI34000 provides sixteen separate 24V AC input points.
• Does it work with both 50Hz and 60Hz power? Yes, it operates across the full 47-63 Hz range.
• What is your return policy? We offer a 30-day return window for unused items in original packaging.
