22F-RF025-BL Allen-Bradley AC Drives

Allen-Bradley 22F-RF025-BL EMC Filter Kit for PowerFlex 4M Drives

Product At A Glance

• Part Number: 22F-RF025-BL
• Compatibility: PowerFlex 4M Drive Series
• Status: In Stock - Ready to Ship
• Condition: New, Original Allen-Bradley

Electrical Ratings & Environmental Specs

• Dual Voltage Input: 100-120V AC or 200-240V AC
• Current Capacity: 25A Maximum
• Frequency: 50/60 Hz Operation
• Operating Temp: -10°C to +40°C
• Storage Temp: -25°C to +70°C
• Max Altitude: 1000m without derating

Physical Dimensions & Installation

• Body Depth: ≤ 65mm
• Unit Weight: 0.6-0.8kg
• Clearance Needed: ≥ 20mm each side
• Shelf Life: 12 months

Key Benefits

• Reduces electromagnetic interference effectively
• Ensures compliance with EMC regulations
• Improves overall system reliability
• Dual voltage support for flexibility
• Compact design saves panel space
• Easy installation with standard tools

What's In The Box?

• EMC Filter Unit (22F-RF025-BL)
• All required mounting hardware
• Installation instructions
• Allen-Bradley quality guarantee

Quick Install Tips

• Allow 20mm minimum side clearance
• Verify voltage setting before power-up
• Use proper torque on connections
• Follow local electrical codes
• Test system after installation

Ordering & Shipping Info

• Availability: In stock, same-day processing
• Shipping: DHL, FedEx, UPS worldwide
• Processing: 1-3 business days
• Returns: 30-day satisfaction guarantee
• Support: Technical assistance available

Common Questions

• What voltages does this filter work with?
  This versatile filter supports both 100-120V and 200-240V AC systems.
• How much current can it handle?
  It's rated for 25 Amps continuous operation.
• Is installation complicated?
  Not at all - it's designed for straightforward mounting with clear instructions.
• Do I need special clearance around the filter?
  Yes, maintain at least 20mm on each side for proper airflow and cooling.
• Is this compatible with my PowerFlex 4M drive?
  Absolutely - it's specifically engineered for the PowerFlex 4M series.
• What's the shelf life?
  12 months when stored in appropriate conditions.
• Do you offer technical support?
  Yes, we provide complete technical support for all our products.

Get Complete Documentation

Download the full technical manual for detailed specifications and installation guidelines:
Download PowerFlex 4M EMC Filter Manual (PDF)
