22D-E1P7F104 | 22D PowerFlex 40P Allen-Bradley

Compact Power Solution for Industrial Applications

Product Identification & Protection

• Manufacturer: Allen-Bradley
• Product Series: PowerFlex 40P
• Model Number: 22D-E1P7F104
• Enclosure Style: Flange Mount, Open Type
• Protection Rating: IP20 to IP65 options available
• Warranty Coverage: 1 year manufacturer warranty
• Frame Design: Size B compact footprint

Electrical Power Specifications

• Input Voltage: 600 Volts AC three-phase power
• Input Frequency: 50 to 60 Hz operating range
• Phase Configuration: Three-Phase input and output
• Current Output: 1.7 Amps maximum capacity
• Power Rating: 1 HP / 0.75 kW motor capability
• Power Efficiency: Optimized for energy savings
• System Compatibility: Works with standard industrial power

Advanced Control Capabilities

• Control Methods: Sensorless Vector and V/Hz operation
• Safety Feature: Optional Safe Torque-Off (Category 3)
• Communication Port: Integral RS-485 for network connectivity
• User Interface: Built-in LED display and keypad
• Position Control: Step Logic for basic positioning
• Feedback System: No encoder required for operation
• Programming Flexibility: Multiple parameter settings

Installation Advantages

• Mounting Benefits: Flange mount saves panel space
• Environmental Protection: Multiple IP ratings available
• Space Efficiency: Compact Frame B design
• Wiring Simplicity: Straightforward connection process
• Maintenance Access: Easy service and parameter adjustment
• System Integration: Compatible with existing controls
• Application Versatility: Suitable for various industries

Shipping & Support Services

• Product Condition: New, factory-sealed units
• Inventory Status: Regularly stocked for quick shipping
• Processing Time: 5 business day shipment guarantee
• Shipping Methods: DHL, FedEx, and UPS available
• Technical Assistance: Application support provided
• Return Policy: 30-day money-back guarantee

Common Technical Questions

What is the power rating of this drive model?

• The 22D-E1P7F104 provides 1 HP (0.75 kW) output capacity

What input voltage does this drive require?

• It operates on 600V AC three-phase power systems

What enclosure options are available?

• Choose from IP20 to IP65 protection ratings

Does it include communication capabilities?

• Yes, it features integral RS-485 communication port

What control methods are supported?

• It offers both Sensorless Vector and V/Hz control

How is the drive mounted?

• This model uses flange mounting for space savings
