22D-B2P3H204 22D PowerFlex 40P Allen-Bradley

Allen-Bradley PowerFlex 40 AC Drive: Compact Motor Control Solution

Model Identification & Physical Dimensions

• Brand & Model: Allen-Bradley 22D-B2P3H204
• Enclosure Type: Open NEMA Type, Plate Mount (IP20)

Electrical Specifications & Power Ratings

• Input Voltage: 240 VAC, 50-60 Hz
• Output Power: 0.5 HP (0.4 kW)
• Rated Current: 2.3 A continuous operation
• Input Power: 1.15 kVA at 2.5 A maximum draw
• Power Dissipation: Only 40 W for energy efficiency
• System Efficiency: High 97.5% rating
• Power Factor: Excellent 0.98 displacement PF

Advanced Control & Performance Features

• Control Methods: Sensorless vector with 100:1 speed range
• Output Frequency: Adjustable from 0 to 500 Hz range
• PWM Technology: Sinusoidal, 2-16 kHz carrier
• Overload Capacity: 150% for 1 minute, 200% for 3 seconds
• Short-Circuit Rating: High 100,000 A withstand capability
• Braking System: IGBT DC injection braking

Comprehensive Protection Systems

• Surge Protection: MOV phase-to-phase and phase-to-ground
• DC Bus Protection: Trips over 405V DC and under 210V DC
• Overcurrent Protection: 200% hardware, 300% instantaneous
• Motor Overload: Class 10 i²t thermal protection
• Power Ride-Through: 100 ms power loss, 2 s logic control

Environmental Specifications & Limits

• Operating Temperature: -10°C to +40°C (14°F to 104°F)
• Storage Temperature: -40°C to +85°C (-40°F to 185°F)
• Humidity Range: 5% to 95% non-condensing environment
• Maximum Altitude: Suitable for installations up to 1000 meters

Installation & Shipping Information

• This compact unit features convenient plate mounting
• Ensure proper ventilation around the drive during installation
• We package each unit securely to prevent transit damage
• Standard shipping via FedEx, UPS, or DHL carriers
• Package includes the drive unit and installation manual

Download Technical Documentation

• Access complete technical specifications and wiring diagrams
• Product Manual: PowerFlex 4 and 40 AC Drives PDF

Frequently Asked Questions

What is the specific model number of this drive?

This unit is the Allen-Bradley 22D-B2P3H204 from the PowerFlex 40 series.

What motor size can this drive control?

The drive controls motors up to 0.5 Horsepower (0.4 Kilowatts).

What input power does this model require?

It operates on standard 240 VAC power at 50-60 Hz frequency.

Are these drives new and available immediately?

Yes, we stock brand new, factory original units for quick shipment.

What is your typical shipping time?

We process and ship all complete orders within five business days.

Which shipping methods do you offer?

We use reliable services including DHL, FedEx, and UPS for delivery.

Do you provide a return policy?

We offer a 30-day return period for all products from delivery date.

For technical support or purchasing assistance, contact our sales team today.

Contact: sales@nex-auto.com
