Bently Nevada 190501-04-00-04 Velomitor CT Velocity Transducer

Technical Specifications

• Brand & Model: Bently Nevada 190501-04-00-04 Velomitor CT series velocity transducer.
• Sensitivity: Provides 3.94 mV/mm/s ±5% output for accurate vibration amplitude measurement.
• Frequency Response: Delivers flat response from 3 Hz to 900 Hz (±1 dB) and extends 1.5 Hz to 1 kHz (±3 dB) for versatile monitoring needs.
• Shock Limit: Withstands extreme impacts up to 5000 g peak without performance degradation.
• Operating Temperature: Functions reliably from -40 °C to +85 °C in harsh industrial environments.
• Amplitude Linearity: Maintains ±2% linearity up to full-scale measurement range for consistent data accuracy.
• Resolution: Achieves fine 0.25 µm/s resolution for detecting subtle vibration changes.
• Output Bias Voltage: Supplies stable 10.1 Vdc ±1 V bias for reliable signal transmission to monitoring systems.
• Resonant Frequency: Features high ≥9 kHz resonant frequency to avoid structural resonance interference.

Environmental & Mechanical Robustness

• Humidity Rating: Operates flawlessly in 100% condensing humidity environments without failure.
• Magnetic Susceptibility: Shows minimal interference at <0.0068 mm/s per gauss @ 50 gauss for superior electromagnetic immunity.
• Case & Connector: Utilizes corrosion-resistant 316L stainless steel for both housing and MIL-C-5015 connector.
• Dimensions & Weight: Measures compact 82 mm height × 33 mm diameter and weighs only 0.297 kg for easy installation.
• Mounting Torque: Requires 4.5 N·m ±0.6 N·m for proper M6×1 plate stud installation with 3/8-24 adapter.
• Storage Temperature: Survives extreme storage conditions from -40 °C to +100 °C without damage.
• Cable Bend Radius: Minimum ≥10 mm bend radius protects cable integrity during routing.

Model Number Breakdown

• 190501 identifies the Velomitor CT family base series.
• -04 specifies M6×1 stud with 3/8-24 adapter mounting hardware configuration.
• -00 indicates the MIL-C-5015 connection interface for secure wiring.
• -04 denotes agency approvals: CSA/NRTL/C, ATEX/IECEx, and CSA Class I, Div 1 & Zone 0/1 certification.

Frequently Asked Questions

• What hazardous area approvals does the 190501-04-00-04 carry?
  This model includes CSA/NRTL/C, ATEX, and IECEx certifications for Class I, Division 1 and Zone 0/1 hazardous locations.
• Is the 190501-04-00-04 compatible with existing Bently Nevada monitoring systems?
  Yes, the Velomitor CT 190501-04-00-04 integrates seamlessly with Bently Nevada vibration monitors and standard industrial PLC systems.
• What is the magnetic field immunity of this sensor?
  The transducer provides exceptional magnetic immunity at <0.0068 mm/s per gauss @ 50 gauss, ensuring stable readings near motors and generators.
• Do you have this model in stock?
  Yes, we maintain brand new original stock of the 190501-04-00-04 ready for immediate shipment.
• What is your return policy?
  We offer 30-day returns for unused items in original packaging. Please contact us for return authorization.
• How quickly will you ship my order?
  We ship within 5 business days after order confirmation via FedEx, UPS, or DHL express services.

Download the complete technical datasheet here: 190501-Datasheet (PDF).
