190501-01-00-CN Bently Nevada Velomitor CT 100mV/in/s Sensor

Bently Nevada 190501-01-00-CN Velomitor CT Velocity Transducer – Industrial Vibration Sensing

• Manufacturer: Bently Nevada – a global leader in machine protection.
• Product type: Velomitor CT Velocity Transducer with model 190501-01-00-CN.
• Made in U.S.A. with a rugged 316L stainless steel case.
• Weight: 0.297 kg (typical <297 g).
• Height: 82 mm; mounting surface diameter: 33 mm.

Electrical Specifications & Sensitivity

• Sensitivity: 3.94 mV/mm/s (100 mV/in/s) ±5% – precise velocity tracking.
• Output bias voltage: 10.1 Vdc ±1.0 Vdc (Pin A to Pin B).
• Dynamic output impedance: <400 Ω typical.
• Broadband noise floor: 0.229 mm/s (0.009 in/s) pk – very low noise.
• Internal electronics isolate from the case for flexible grounding.

Frequency Response & Linearity

• Frequency response: 3.0 Hz to 900 Hz (180–54,000 cpm) ±1.0 dB.
• Extended range: 1.5 Hz to 1.0 kHz (90–60,000 cpm) ±3.0 dB.
• Amplitude linearity: ±2% up to 63.5 mm/s pk (2.5 in/s pk).
• Mounted resonant frequency: 9 kHz minimum (stud mounted).
• Transverse response: less than 5% of axial sensitivity – minimal cross-axis error.

Environmental & Mechanical Limits

• Operating temperature: -40°C to +85°C (-40°F to +185°F).
• Storage temperature: -40°C to +100°C (-40°F to +212°F).
• Shock limit: 5000 g pk maximum – survives severe impacts.
• Humidity: 100% condensing (non-submerged).
• Magnetic field susceptibility: <0.0068 mm/s/gauss at 50 gauss, 50-60Hz.
• Base strain sensitivity: 0.43 mm/s/μstrain (0.017 in/s/μstrain).
• Maximum cable length: 305 meters (1,000 ft.) with part 02173006 – no signal degradation.

Frequently Asked Questions (FAQ)

• Is the 190501-01-00-CN brand new and original?
  Yes, we supply only factory new and original Bently Nevada units.
• Do you have this model in stock?
  Yes, we keep 190501-01-00-CN in stock for immediate orders.
• How fast will you ship?
  We ship within 5 business days after order confirmation.
• Which carriers do you use?
  We use FedEx, UPS, and DHL for reliable worldwide delivery.
• What is the return policy?
  You can return the transducer within 30 days for a full refund.
• Can I use this transducer at high temperatures?
  Yes, it operates from -40°C to +85°C without issues.
• What happens if I exceed the cable length limit?
  Exceeding 305 meters may degrade the dynamic signal quality.
• Is the case electrically grounded?
  No, the internal electronics isolate from the case for floating installations.
