1756-IB32/B Input Module Allen-Bradley

Allen-Bradley 1756-IB32/B ControlLogix Digital Input Module

Key Technical Specifications

• The 1756-IB32 operates within a wide voltage range of 10 to 31.2 Volts DC
• This high-density module provides 32 input channels in two groups
• It features configurable input filters from 0 to 18 milliseconds
• The module draws 120 milliamps at 5.1 Volts from the backplane
• Maximum power dissipation is 6.2 Watts at 60°C
• Fast hardware response with 380μs OFF to ON delay
• Brand: Allen-Bradley, Model: 1756-IB32/B

Installation and Configuration

• Install in any single slot of a ControlLogix chassis
• Use 1756-TBCH or 1756-TBS6H removable terminal blocks
• Configure RPI and filter settings via Studio 5000 software
• Electronic keying prevents module mismatches
• Built-in diagnostics monitor module and backplane status

Packaging and Shipping

• Brand new, factory-sealed units only
• Includes module and removable terminal block
• We ship within 5 business days
• Carriers: DHL, FedEx, and UPS available

Frequently Asked Questions

Is the Allen-Bradley 1756-IB32 module brand new and authentic?

• Yes, we supply only 100% brand new and genuine Allen-Bradley products

What is the operating voltage range for this input module?

• The 1756-IB32/B accepts 10 to 31.2 Volts DC input range

How many input points does this ControlLogix module have?

• This module has thirty-two input points in two groups

Can I adjust the module's response time?

• Yes, configurable input filters from 0 to 18 ms are available

What is your shipping and return policy?

• We ship within 5 days and offer 30-day returns
