140SACQDNET010 Schneider Electric Modicon Scanner Module DeviceNet

Schneider Electric 140SACQDNET010 Modicon Scanner Module Overview

Key Technical Specifications

• Manufacturer: Schneider Electric ensures premium quality and reliability.
• Series: Modicon series designed for industrial control and automation applications.
• Part Number: 140SACQDNET010 with unique identification for ordering and replacement.
• Product Type: Scanner module specifically engineered for DeviceNet communication protocols.
• DeviceNet Support: Fully compatible with DeviceNet networks for seamless field device integration.
• Voltage Type: DC operation with nominal voltage of 24V DC for industrial control systems.
• Current Rating: 90 mA power consumption for energy-efficient operation.
• I/O Configuration: Supports 8/32 I/O connections for flexible application adaptability.
• Operating Temperature: Functions reliably from 0 to 40 degrees Celsius in control environments.
• Storage Temperature: Safely stores from 0 to 50 degrees Celsius for inventory flexibility.
• Operating Humidity: Rated for 80% non-condensing relative humidity for dependable performance.
• Storage Humidity: Maintains 80% non-condensing relative humidity rating during storage.
• Maximum Altitude: Installs up to 1000 meters above sea level for various geographical locations.
• Weight: Approximately 0.74 pounds for lightweight handling during installation.

Communication and Network Integration

• The 140SACQDNET010 serves as a master scanner for DeviceNet networks in Modicon systems.
• It enables efficient data exchange between the PLC processor and DeviceNet slave devices.
• DeviceNet protocol support allows integration with sensors, actuators, and other field devices.
• The scanner module handles both polled and strobed I/O data transmission methods.
• It supports explicit messaging for device configuration and diagnostics.
• The 140SACQDNET010 simplifies network wiring using standard DeviceNet cabling infrastructure.

Environmental Specifications and Installation Requirements

• You can install the 140SACQDNET010 in control cabinets with ambient temperatures from 0 to 40 degrees Celsius.
• The module operates reliably in environments with up to 80% non-condensing relative humidity.
• Installation sites must not exceed 1000 meters above sea level for guaranteed performance.
• Storage facilities should maintain temperatures between 0 and 50 degrees Celsius.
• The lightweight 0.74 pound design puts minimal stress on DIN rail or panel mounting hardware.
• Proper ventilation around the module ensures optimal thermal performance during operation.

I/O Configuration and System Compatibility

• The 140SACQDNET010 supports 8/32 I/O configuration for flexible application matching.
• It integrates seamlessly with Modicon programmable logic controllers in automation systems.
• The scanner module communicates with up to 63 DeviceNet nodes on a single network.
• It supports both input and output data mapping for comprehensive device control.
• The module automatically detects DeviceNet baud rates for simplified network setup.
• LED indicators provide visual status for network activity and module health.

Frequently Asked Questions (FAQ)

• Is the Schneider Electric 140SACQDNET010 a new or used module?
  We supply a brand new original 140SACQDNET010 unit with full factory specifications and certifications.
• What communication protocol does the 140SACQDNET010 support?
  This Modicon scanner module supports DeviceNet protocol for industrial device networking.
• What is the voltage and current requirement for this module?
  The 140SACQDNET010 operates at 24V DC and consumes 90 mA of current.
• What I/O configuration does this scanner module support?
  The module supports 8/32 I/O configuration for flexible integration with field devices.
• What is the operating temperature range for this module?
  The scanner operates reliably from 0 to 40 degrees Celsius in control environments.
• Do you have the 140SACQDNET010 in stock?
  Yes, we have stock available and typically ship orders within 5 working days.
