Allen-Bradley 1756-L62 Processor Module

1756-L62 ControlLogix processor Allen-Bradley

Technical Specifications

• Brand: Allen-Bradley
• Model: 1756-L62
• Series: ControlLogix 5562
• Module Type: Processor Module
• User Memory: 4 MB program storage
• I/O Memory: 478 KB dedicated capacity
• Non-Volatile Memory: 64 MB CompactFlash

Memory & Processing

• 4 MB user memory for program and data storage
• 478 KB high-speed I/O memory
• 64 MB CompactFlash non-volatile memory
• Supports 1784-CF128 memory card expansion
• 32 task capacity with 100 programs per task
• 0.08 millisecond program scan time

Communication Interfaces

• RS-232 serial port for direct connectivity
• Supports DF1, DH-485, and Modbus protocols
• EtherNet/IP network communication
• ControlNet and DeviceNet compatibility
• Data Highway Plus protocol support
• Remote I/O and SynchLink capabilities

I/O Capacity & Performance

• Maximum Digital I/O: 128,000 points
• Maximum Analog I/O: 4,000 points
• Supports 250 simultaneous controller connections
• Full controller redundancy support
• Multiple controller backplane communication
• Third-party network integration

Power Requirements

• Backplane Current: 1.2A at 5V DC
• 24V DC Current: 14 mA auxiliary
• Power Dissipation: 3.5 Watts maximum
• Thermal Output: 11.9 BTU per hour
• Isolation Rating: 30 Volts continuous
• 1756-BA1 battery for memory backup

Environmental Specifications

• Operating Temperature: 0°C to 60°C
• Storage Temperature: -40°C to 85°C
• Relative Humidity: 5% to 95% non-condensing
• Vibration Resistance: 2g at 10-500 Hz

Frequently Asked Questions

Is the 1756-L62 still available?
Yes, we supply new original units as replacement stock.

What memory capacity does it have?
The controller features 4 MB user memory and 478 KB I/O memory.

How many I/O points does it support?
It supports up to 128,000 digital and 4,000 analog I/O points.

What is the shipping time?
We process and ship orders within 5 business days.

Does it support network communication?
Yes, supports EtherNet/IP, ControlNet, DeviceNet and more.

What is the return policy?
30-day return period for unused products in original packaging.
