330905-00-03-10-01-CN Bently Nevada - Proximity Probe

Bently Nevada 3300 NSv Proximity Probe – Model 330905-00-03-10-01-CN

• Brand: Bently Nevada
• Model: 330905-00-03-10-01-CN
• Series: 3300 NSv Proximity Probes
• Thread size: M10 x 1 without armor
• Total probe length: 1.0 meter (39 inches)
• Connector type: Miniature coaxial ClickLoc with connector protector
• Agency approval: CN Country Specific Approval

Technical Specifications

• Linear range: 1.5 mm (60 mils) from 0.25 mm to 1.75 mm (-1 to -13 Vdc)
• Recommended gap setting: 1.0 mm (40 mils)
• Incremental scale factor (ISF): 7.87 V/mm (200 mV/mil) with +12.5%/-20% interchangeability error
• Deviation from best fit straight line (DSL): Less than ±0.06 mm (±2.3 mils)
• Frequency response: 0 to 10 kHz with +0, -3 dB typical for up to 305 m field wiring
• Probe DC resistance (1.0m): 4.2 ± 0.5 ohms from center to outer conductor
• Extension cable DC resistance: Center 0.220 Ω/m, Shield 0.066 Ω/m
• Extension cable capacitance: 69.9 pF/m typical
• Field wiring: 0.2 to 1.5 mm² (16-24 AWG) triad cable, maximum length 305 m (1000 ft)

Environmental & Mechanical Ratings

• Operating temperature: -52°C to +177°C (-62°F to +351°F)
• Storage temperature: -52°C to +177°C (-62°F to +351°F)
• Probe tip material: Polyphenylene sulfide (PPS)
• Probe case material: AISI 304 stainless steel (SST)
• Probe cable: 75 Ω coaxial, FEP insulated
• Minimum bend radius: 25.4 mm (1.0 inch) with or without SST armor
• Recommended torque: Finger tight. Maximum torque 0.56 N•m (5 in•lb)
• Case thread torque (M10x1): Maximum 22.6 N•m (200 in•lb). Recommended 7.5 N•m (66 in•lb)
• Maximum thread engagement length: 15 mm for M10x1
• Pressure sealing: Viton O-ring design for differential pressure

Frequently Asked Questions (FAQ)

• Is this 330905-00-03-10-01-CN a new original part?
  Yes. This 3300 NSv probe comes new and original in factory packing. We keep it in stock.
• What is the linear range of the Bently Nevada 3300 NSv probe?
  The linear range starts at 0.25 mm from the target. It extends to 1.75 mm, giving a total of 1.5 mm (60 mils).
• Can I use this probe with the old 3300 RAM extension cable?
  Yes. The 3300 NSv probe is mechanically and electrically interchangeable with the 3300 RAM probe and cable.
• What is the maximum field wiring length for the 3300 NSv system?
  You can use up to 305 meters (1000 feet) of three-conductor shielded triad cable between the Proximitor Sensor and monitor.
• How does temperature affect the Bently Nevada 330905 probe?
  The probe operates from -52°C to +177°C. It stores at the same range without performance loss.
• What does the CN approval mean for this probe?
  The 330905-00-03-10-01-CN carries Country Specific Approval for China. This meets local regulatory requirements.
• What shipping carriers do you use?
  We ship via FedEx, UPS, or DHL. All orders leave our warehouse within 5 days.
• Can I return this probe if it does not fit my machine?
  Yes. You have 30 days from delivery to return the 330905-00-03-10-01-CN for a refund.
