Schneider Electric 140CPU53414A Modicon Quantum CPU Processor

Schneider Electric 140CPU53414A Modicon Quantum Processor Unit

Core Technical Specifications

• Brand & Model: Schneider Electric 140CPU53414A.
• Processor: An efficient 80586 type CPU with a 133 MHz clock frequency for fast execution.
• Memory: Equipped with 2.7 MB of internal memory for program and data storage.
• Math Coprocessor: Integrated for enhanced calculation speed in complex applications.
• Module Support: This unit can manage and communicate with up to 6 additional I/O or special modules.
• Communication Ports: Includes both RS-232 and RS-485 serial ports for network connectivity.
• Security: Features a physical key switch for access control and operational mode selection.

Environmental Durability & Power

• Operating Temperature: Functions reliably in a 0°C to 60°C range.
• Storage Temperature: Can withstand non-operating conditions from -40°C to 85°C.
• Battery: Uses a 3V lithium battery (1200 mAh) for memory backup.
• Battery Life: Offers a service life of 1200 mAh and a 10-year shelf life.
• Weight: The unit weighs 2.00 lbs (0.91 kg) for easy handling and installation.

Frequently Asked Questions (FAQ)

• Q: What processor does this Modicon Quantum CPU use?
  A: The 140CPU53414A uses a high-performance 80586 processor running at 133 MHz.
• Q: How much memory is available on this PLC processor?
  A: It has 2.7 MB of internal memory, supported by a dedicated math coprocessor.
• Q: What is the operating temperature range?
  A: This Schneider Electric CPU operates reliably from 0°C to 60°C.
• Q: How many modules can I connect to this unit?
  A: You can expand your system by connecting up to 6 modules to this base processor.
• Q: What is your return policy?
  A: We offer a 30-day return policy for items in original condition.

For technical specifications or purchasing information on the 140CPU53414A, please contact us.
