IV4-G500CA Keyence Compact Color Sensor Head

IV4-G500CA Compact Color Sensor Head by Keyence — IV4 Series Standard Field of View

Key Technical Specifications

• Brand: Keyence
• Model: IV4-G500CA
• Series: IV4 Series
• Category: Compact color sensor head, standard field of view
• Image sensor: 1/2.9 inch color CMOS with 1280 (H) x 960 (V) pixels
• Installed distance: starts from 50 mm
• Field of view: 22 x 16 mm at 50 mm distance, up to 1184 x 888 mm at 3000 mm distance (reference values)
• Focus adjustment: automatic
• Exposure time: 12 µs to 9 ms
• Illumination: white LED with switchable pulse and continuous lighting
• Power consumption: 2.5 W without AI imaging illumination unit, 6.6 W with it
• Supply voltage: provided by the connected amplifier
• Output type: not available on the head; outputs run through the amplifier

Environmental Tolerance and Anti-Interference

• Operating temperature: 0 to +50°C with no freezing
• Relative humidity: 85% RH or less with no condensation
• Protection rating: IP67, except when you install polarizing filters OP-88642, OP-88643, OP-88646, or OP-88647; the rating does not apply when you mount OP-88909
• Vibration resistance: 10 to 500 Hz at 0.816 G²/Hz across X, Y, and Z directions
• Shock resistance: 500 m/s², three times in each of six directions
• ESD safety: complies with IEC61340-5-1

FAQ

• Q: What is the difference between the IV4-G500CA and other IV4 heads?
  A: This model is a compact color head with a standard field of view. It uses a color CMOS sensor for color inspection tasks.
• Q: Which amplifier does this sensor head work with?
  A: It works with the Keyence IV4-G120 amplifier. The amplifier supplies power and handles all outputs.
• Q: What field of view can I expect?
  A: You get 22 x 16 mm at 50 mm distance and up to 1184 x 888 mm at 3000 mm distance as reference values.
• Q: Does the IV4-G500CA have a built-in output?
  A: No. Outputs run through the connected IV4-G120 amplifier, not from the head itself.
• Q: What is the exposure time range?
  A: The exposure time ranges from 12 µs to 9 ms, which covers fast moving and slower targets.
• Q: Is the sensor head waterproof?
  A: Yes, it carries an IP67 rating. However, the rating does not apply when you install certain polarizing filters or mount OP-88909.
• Q: How much does the IV4-G500CA weigh?
  A: It weighs about 75 g without the AI imaging illumination unit and about 225 g with it.
• Q: What is the lead time and shipping method?
  A: We keep stock and ship within 5 days by FedEx, UPS, or DHL. We accept returns within 30 days.
