Proximitor Sensor - Bently Nevada - 330980-71-00

Bently Nevada NSv Proximitor Sensor 330980-71-00

Product Overview

• The Bently Nevada 330980-71-00 serves as a precision proximity measurement device.
• This sensor provides accurate vibration monitoring for industrial machinery systems.
• It maintains reliable operation even in challenging environmental conditions.
• Engineers trust this transducer for critical protection and monitoring applications.

Power Supply & Electrical Specifications

• The unit accepts input from one 3300 RAM or NSv probe with extension cable.
• Operating power without barriers ranges from -17.5 Vdc to -26 Vdc at 12 mA maximum.
• With safety barriers, required power is -23 Vdc to -26 Vdc for proper function.
• Note that input voltage exceeding -23.5 Vdc may decrease the measurement range.
• The output resistance is specified at 50 Ω for standard system compatibility.
• Power supply sensitivity remains below 2 mV change per 1 volt input variation.

Physical Construction & Design

• The sensor features a durable A380 aluminum housing for protection.
• This robust casing ensures longevity in demanding industrial environments.
• The complete unit weighs only 255 grams (9 ounces) for easy handling.
• Its compact design allows simple installation in various mounting configurations.

Environmental Operating Conditions

• Operating temperature spans from -52°C to +100°C (-62°F to +212°F).
• Storage temperature range is -52°C to +105°C for proper preservation.
• The sensor withstands 100% condensing humidity with protected connectors.
• Maximum operational altitude is 2000 meters above sea level.
• Calibration requires AISI 4140 steel target measuring 31 mm or larger.
• Optimal probe gap for accuracy is 1.0 mm (40 mils) with 10 kΩ load.
• Rated test conditions are 0°C to +45°C (32°F to 113°F) for specification verification.

Frequently Asked Questions (FAQ)

• What is the product condition?
  We supply only brand new, original units with full manufacturer specifications.
• Is this model currently available?
  Yes, we maintain stock of the 330980-71-00 for immediate order processing.
• What is your shipping timeline?
  We dispatch all orders within 5 business days after payment confirmation.
• Which shipping methods do you offer?
  We use major carriers including DHL, FedEx, and UPS for reliable delivery.
• Do you accept returns?
  We provide a 30-day return window for unused items in original packaging.
• What target material works best?
  For precise calibration, use AISI 4140 steel with minimum 31 mm diameter.

Access the complete technical documentation by downloading the datasheet here: 3300 XL NSv Proximity Transducer System Datasheet - 147385
