New Bently Nevada 990-04-70-02-01 - In Stock Vibration Transmitter

Bently Nevada 990 Vibration Transmitter: Reliable Machine Health Monitoring

Core Technical Specifications

• Brand & Model: This unit is the Bently Nevada 990-04-70-02-01.
• Measurement Range: The device accurately measures vibration from 0 to 4 mils (0 to 100 micrometers peak-to-peak).
• Frequency Response: It detects vibration frequencies within a broad range of 5 Hz to 6,000 Hz.
• Output & Accuracy: The transmitter provides a highly reliable 4-20 mA, two-wire output signal. It maintains an excellent accuracy of ±1.5% across its full measurement scale.
• Power Supply: The unit operates on a 12-35 VDC loop power supply, with 28 VDC recommended for installations in hazardous locations.

Environmental Durability & Compliance

• Operating Temperature: It performs consistently in extreme temperatures from -40°C to 85°C (-40°F to 185°F).
• Environmental Protection: The housing can withstand environments with up to 95% relative humidity, non-condensing.
• Hazardous Area Certification: The transmitter carries approvals for use in Class I, Zone 2/Division 2 hazardous locations.
• Electrical Protection: It includes built-in current limiting at 23 mA to protect against overload conditions.

Installation & Integration Guide

• Compatible Sensor: The transmitter works with one Bently Nevada 3300 NSv proximity probe.
• Probe Gap Setting: For optimal performance, set the probe tip to target gap between 0.5 mm and 1.75 mm (20-55 mils).
• Target Requirements: Ensure the observed target material is ferrous and has a minimum diameter of 9.5 mm (0.375 inches).
• Cable & Load: Use a maximum probe cable length of 3 meters. The total loop resistance must be less than 1000 Ohms at 35 VDC.
• Fault Indication: The output will drop below 3.6 mA within 100 microseconds to signal a system fault, resetting within 2-3 seconds.

Packaging & Shipping Information

• Packaging List: Each unit ships as a complete, brand new and original item. The package includes the Bently Nevada 990-04-70-02-01 vibration transmitter unit.
• Unit Weight: The compact transmitter weighs only 0.43 kg (0.9 lbs), allowing for easy installation in tight spaces.
• Shipping: We ship all items from our in-stock inventory within 5 business days. We use reliable global carriers like FedEx, UPS, and DHL.
• Return Policy: We support a 30-day return policy for your peace of mind.

Frequently Asked Questions (FAQ)

• Q: What is the exact measurement range of this model?
  A: The 990-04-70-02-01 model has a range of 0 to 4 mils, which is 0 to 100 micrometers peak-to-peak displacement.
• Q: Can this transmitter work in very hot or cold environments?
  A: Yes. The Bently Nevada 990 series is built to operate in a wide temperature range from -40°C to 85°C.
• Q: What happens if the connected probe fails?
  A: The transmitter has a fast fault response. Its output current will go below 3.6 mA to quickly alert your control system of a problem.
• Q: Is this item ready to ship?
  A: Yes. We have this genuine Bently Nevada transmitter in stock, and we will dispatch it within 5 business days.
• Q: What power supply do I need for installation?
  A: You need a standard 2-wire loop power supply between 12 and 35 VDC. For hazardous areas, a 28 VDC supply is recommended.

For more detailed wiring diagrams and specifications, please download the complete datasheet. Download the 990 Vibration Transmitter Datasheet PDF here.
