Lenze EMB9342-C Regenerative Power Supply Module

Lenze EMB9342-C Regenerative Power Supply: Efficient Energy Recovery

Technical Specifications & Core Features

• Brand: Lenze
• Model: EMB9342-C
• Product Type: Regenerative Power Supply Module
• Rated Active Power: 14 kilowatt
• Maximum Output Power: 21.6 kilowatt
• Operating Voltage Range: 320 to 528 Volts AC
• Main Frequency Range: 48 to 62 Hertz
• Rated DC Bus Current: 26 Amperes
• Maximum Current: 36 Amperes
• Apparent Power Capacity: 16.6 kilo-volt-amperes
• Estimated Power Loss: 200 Watts
• Protection Class: IP20

Environmental & Installation Specifications

• Ambient Operating Temperature: 0 to 40°C (non-freezing)
• Installation Altitude: 1,000 to 4,000 meters (with derating)
• Frequency Stability: Can tolerate fluctuations within 48-62 Hz range
• Environmental Tolerance: Designed for standard industrial settings
• Interference Immunity: Built to withstand typical electrical noise

Frequently Asked Questions

What are the key technical specs of the Lenze EMB9342-C?

The EMB9342-C provides 14 kW rated power with a 21.6 kW peak output. It works with 320-528V AC input and has a 26A rated DC bus current.

What is the operating temperature range for this unit?

This module operates within a temperature range of 0°C to 40°C. You must install it in a non-freezing environment.

Can it handle different input voltages and frequencies?

Yes, the power supply accepts a wide 320-528V AC range and works from 48 to 62 Hz. It also tolerates frequency changes within this band.

What is the return policy for this product?

We offer a 30-day return window for unused items in their original packaging.

How quickly will my order ship?

We process orders from available stock and aim to ship within 5 business days via carriers like DHL, FedEx, or UPS.

What protection does the IP20 rating provide?

The IP20 class protects against solid objects larger than 12.5mm, like fingers. It is not protected against water ingress.
