IV3-LG5C Keyence AI Imaging Illumination Unit White LED

IV3-LG5C AI Imaging Illumination Unit for Keyence IV3 Series Sensor Heads

Technical Specifications

• Brand: Keyence
• Model: IV3-LG5C
• Series: IV3 Series
• Category: AI imaging illumination unit (side light)
• Compatible Sensor: IV3-G500CA
• Illumination Type: White LED
• Built-in Ports: None
• Protocols: None
• Communication Expansion: None
• Supply Voltage: Power supplied by the connected sensor
• Power Consumption: Not available
• Output Type: Not available

Environmental and Physical Data

• Operating Temperature: 0 to +50°C, no freezing
• Relative Humidity: 35 to 85% RH, no condensation
• Protection Rating: IP67, applicable only when mounted to a compatible sensor
• IP67 Exception: Rating does not apply when a polarizing filter (OP-88644/OP-88645/OP-88646/OP-88647) is mounted
• Dimensions (H×W×D): Not available
• Weight: Approx. 150 g
• Unit Case Material: Aluminum die-casting and PBT
• Sensor Head Connector Material: Zinc with Ni plating and PA
• Front Cover Material: Acrylic
• Cable Material: PVC, Ni plating, and TPEE

Key Performance Highlights

• The white LED side light delivers uniform illumination for consistent AI imaging results.
• An IP67 rating protects the unit from dust and water ingress during normal operation.
• The aluminum die-cast body resists vibration and mechanical stress on the production line.
• Power comes from the sensor head, which simplifies wiring and reduces installation time.
• The unit operates reliably across a 0 to +50°C temperature range without performance loss.

Installation Guide

• Mount the IV3-LG5C onto the IV3-G500CA sensor head and tighten the connector firmly.
• Confirm the seal sits flush, because the IP67 rating depends on a proper sensor connection.
• Remove any polarizing filter before you rely on the IP67 protection rating.
• Route the PVC cable away from heat sources and moving parts to avoid damage.
• Verify the ambient temperature stays between 0 and +50°C with no freezing.
• Keep relative humidity within 35 to 85% RH and prevent condensation on the unit.

Packing List

• 1 × Keyence IV3-LG5C AI imaging illumination unit
• 1 × Sensor head connector
• 1 × Cable
• 1 × Protective front cover
• 1 × Quick reference guide

Shipping and Delivery

• We ship orders through FedEx, UPS, and DHL for fast global delivery.
• We dispatch in-stock items within 5 days after order confirmation.
• We keep this IV3-LG5C in stock as a new original unit.
• We support returns within 30 days of delivery.

FAQ

• Q: Which sensor head does the IV3-LG5C work with?
  A: The unit works with the Keyence IV3-G500CA sensor head from the IV3 Series.
• Q: Does the IV3-LG5C need a separate power supply?
  A: No, the connected sensor head supplies all power to the unit.
• Q: What is the IP rating of this illumination unit?
  A: The unit carries an IP67 rating when you mount it to a compatible sensor.
• Q: Does the IP67 rating apply with a polarizing filter?
  A: No, the rating does not apply when you mount a polarizing filter.
• Q: What temperature range does the IV3-LG5C support?
  A: The unit operates from 0 to +50°C with no freezing.
• Q: How much does the IV3-LG5C weigh?
  A: The unit weighs approximately 150 g.
• Q: How do you ship orders?
  A: We ship through FedEx, UPS, and DHL for reliable worldwide delivery.
