EVS9329-ES Lenze Servo Inverter | 46.6 kVA 480V Drive

Lenze EVS9329-ES Servo Inverter Overview

• Core Output Specifications: The EVS9329-ES provides 30 kW for 400V 4-pole ASM motors and 37 kW for 480V setups. It achieves an impressive peak output current of 88.5 A at 8 kHz for 480V systems.
• Switching Frequency Details: At 8 kHz, the output current reaches 47 A for 400V and 56 A for 480V. For 16 kHz operation, the module delivers 38 A at 400V and 35 A at 480V, allowing flexibility for noise-sensitive applications.
• Power Supply Flexibility: This servo inverter accepts a three-phase mains voltage from 320 to 528 VAC with a frequency range of 45 to 65 Hz. It also supports an alternative DC supply between 460 and 740 VDC.
• Environmental and Installation: The inverter operates reliably in standard industrial environments. Mount the device vertically on a flat surface to ensure proper cooling and airflow.

Frequently Asked Questions (FAQ)

• What is the maximum motor power for the EVS9329-ES at 480V?
  It supports up to 37 kW for a 4-pole ASM induction motor when operating at 480V mains supply.
• Can I use a DC power source with this servo inverter?
  Yes, the EVS9329-ES accepts an alternative DC input ranging from 460 to 740 VDC, offering flexibility for various power architectures.
• How does the switching frequency affect output current?
  At 8 kHz, the unit delivers higher current (up to 88.5A peak). At 16 kHz, the current reduces to manage heat dissipation while maintaining performance.
• What are the exact dimensions for installation planning?
  The module measures 250mm width, 350mm height, and 250mm depth, with a mass of 12.5 kg for easy handling.
• Do you ship this item internationally and how fast?
  We ship globally via FedEx, UPS, or DHL. Orders typically dispatch within 5 days from our warehouse.
