Bently Nevada Proximity Probes | 24701-28-10-00-040-04-02

Bently Nevada 24701-28-10-00-040-04-02 Proximity Sensor Kit

Key Features & Compliance

• This is a brand new, factory-original monitoring sensor kit.
• It features a corrosion-resistant construction using 303 and 304 Stainless Steel.
• The kit is designed with a 4-inch (101.6 mm) probe penetration depth.
• It is fully API 670 compliant for machinery protection systems.
• The materials and finish meet NACE MR0103 standards for sour service environments.
• It comes with a comprehensive 12-month manufacturer's warranty against defects.

Technical Specifications

• Brand & Manufacturer: Bently Nevada
• Full Part Number: 24701-28-10-00-040-04-02
• Probe System: 3300 XL 8mm diameter proximity probe.
• Probe Penetration: 4 inches (as indicated by suffix '040').
• Attached Cable: 1 meter (39 inches) in length.
• Thread Standard: 3/4-14 NPT mounting threads on the housing.
• Housing Material: Primary body made of Type 303 Stainless Steel.
• Sleeve Material: Probe sleeve made of Type 304 Stainless Steel.
• Visible Length: Maximum visible probe length is approximately 17.0 inches (43.18 cm).
• Total Assembly Depth: Overall depth measures about 29.2 inches (74.2 cm).
• Approximate Weight: 4.1 lbs (1.8 kg).
• System Compatibility: Works with Bently Nevada 3300 and 3500 series monitoring systems.

Part Number Configuration Breakdown

• Each segment of the suffix defines a specific attribute of the kit.
• 28: Denotes an 8mm probe for the 3300 XL system.
• 10: Specifies a 1-meter (39") integrated cable.
• 00: Means no standoff adapter is included.
• 040: Indicates a 4-inch probe reach.
• 04: Signifies inclusion of a 3/4-14 NPT plug.
• 02: Defines the housing's 3/4-14 NPT threaded connection.

Complete Kit Contents

• One Bently Nevada 24701-28-10-00-040-04-02 sensor assembly.
• Protective dome cover for the sensitive probe tip.
• Required O-rings and a thread sealant for leak-proof installation.
• A reverse-mount style proximity probe.
• 3/4-14 NPT threaded plug for conduit connection.
• Stainless steel probe sleeve.
• The kit supports cable diameters from 1/8 inch to 3/8 inch.
• All components arrive in original, security-sealed factory packaging.

Packaging & Shipping Information

• We stock this item and ensure it is shipped in its sealed, protective packaging.
• Orders are processed promptly and dispatched via global carriers like DHL, FedEx, or UPS.
• Standard shipping time is within five business days from order confirmation.

Documentation & Support

• For full engineering specifications and installation drawings, please download the datasheet.
• Access the official product datasheet here: 21000-24701-Datasheet.pdf

Frequently Asked Questions (FAQ)

• Q: Is this sensor kit new and does it have a warranty?
  A: Yes, it is new and factory-sealed with a full 12-month warranty.
• Q: What is the probe length?
  A: This model has a 4-inch (040) probe penetration depth.
• Q: What thread size is it?
  A: It uses standard 3/4-14 NPT threads for mounting and connections.
• Q: Is it suitable for harsh environments?
  A: Yes, its stainless steel construction meets NACE MR0103 standards for corrosion resistance.
• Q: What systems is it compatible with?
  A: It is designed for Bently Nevada 3300 and 3500 series monitoring systems.
• Q: What is your shipping and return policy?
  A: We ship quickly and offer a 30-day return policy on unused, original items.
