Armored Probe Bently Nevada | 330904-08-15-50-12-05

Bently Nevada 3300 NSv Proximity Probe – Model: 330904-08-15-50-12-05

Product Configuration & Ordering Details

The full part number defines the exact probe build. Here are the details for your selected configuration.

• Brand & Base Model: Bently Nevada 330904 (3300 NSv Probe, M8x1 thread, armored)
• Full Suffix Breakdown:
  • -08 : Unthreaded probe length is 80 mm.
  • -15 : Overall case length measures 150 mm.
  • -50 : Total attached cable length is 5.0 meters (16.4 feet).
  • -12 : Features a miniature coaxial ClickLoc connector with FluidLoc cable.
  • -05 : Includes multiple international agency approvals.

Electrical & Signal Performance

This probe ensures accurate and reliable signal transmission for condition monitoring.

• Probe DC Resistance: Measures 5.3 Ω ± 0.7 Ω at the standard 5.0 m cable length.
• Extension Cable Specs: Center conductor: 0.220 Ω/m, Shield: 0.066 Ω/m.
• Capacitance: Cable capacitance is 69.9 pF per meter.
• Field Wiring: Use 0.2 to 1.5 mm² (16 to 24 AWG) wire for best results.
• Max Wiring Distance: Supports up to 305 meters (1000 feet) of field wiring.

Measurement Range & Accuracy

Designed for precise gap measurement in dynamic machinery applications.

• Linear Measurement Range: 1.5 mm (60 mils).
• Optimal Gap Setting: We recommend 1.0 mm (40 mils).
• Scale Factor (ISF): 7.87 V/mm (200 mV/mil) with a defined tolerance.
• Linearity Deviation: Less than ±0.06 mm (±2.3 mils) from the best fit line.
• Frequency Response: 0 to 10 kHz, typical across the maximum wiring length.

Frequently Asked Questions (FAQ)

• What is the brand and condition of this probe?
  This is a brand new and 100% genuine Bently Nevada product from original packaging.
• Is this item in stock and what is the shipping time?
  Yes, this model is in stock. We process and ship orders within 5 business days.
• What shipping methods are available?
  We ship worldwide using reliable carriers like DHL, FedEx, and UPS.
• Do you accept returns?
  Yes, we offer a 30-day return policy for items in new, unused condition.
• What is the purpose of the "FluidLoc" cable?
  The FluidLoc cable provides enhanced resistance to moisture and fluids for reliable operation.
• Can I use a different extension cable length?
  The attached cable is 5.0 meters. You can extend it using compatible cables up to the 305-meter maximum.
• What is the operating temperature range?
  Please refer to the full datasheet for detailed temperature ratings and environmental limits.

Download the Complete Technical Datasheet Here: 3300 XL NSv Proximity Transducer System Datasheet - 147385
