Allen-Bradley 1794-IB10XOB6 Digital I/O Module

Allen-Bradley 1794-IB10XOB6 Digital Combination I/O Module

Core Technical Specifications

• Brand: Allen-Bradley
• Model: 1794-IB10XOB6
• Series: Flex I/O 1794
• Product Type: Digital Combination I/O Module
• Input Specifications:
  • Quantity: 10 Current Sink Inputs
  • Nominal Voltage: 24 VDC
  • On-State Current: 8 mA at 24 VDC
  • Input Impedance: 4.8 kilohms
• Output Specifications:
  • Quantity: 6 Current Source Outputs
  • Nominal Voltage: 24 VDC
  • Maximum Current per Channel: 2 A
• System Performance:
  • Flexbus Current: 50 mA
  • Operating Temperature Range: -20°C to 55°C
  • Environmental Rating: Open (No IP Rating)

Frequently Asked Questions (FAQ)

• Q: Is this module brand new and original?
  A: Yes, every 1794-IB10XOB6 we sell is 100% brand new and original from Allen Bradley.
• Q: What is the main function of this module?
  A: It is a combination digital I/O module. It reads signals from 10 input devices and controls power to 6 output devices, all at 24VDC.
• Q: Can I use this module in a dusty environment?
  A: No, this module has an "Open" rating. You must install it inside a protected enclosure away from dust and liquids.
• Q: How many outputs does it have and what is their capacity?
  A: It has 6 outputs. Each output channel can handle a maximum load current of 2 Amps at 24 VDC.
• Q: What is your return policy?
  A: We offer a 30-day return policy for unused items in their original packaging.
