ABB DI524 Digital Input Module 32 DI 24VDC

ABB DI524 S500 Digital Input Module

The DI524 is a high-density digital input module from the ABB S500 I/O series. It provides 32 channels for monitoring 24V DC signals in distributed automation applications.

Core Technical Specifications

• Brand: ABB
• Product ID: 1SAP240000R0001
• Extended Product Type: DI524
• Catalog Description: Digital input module. 32 DI: 24VDC
• Function: 32 Digital Inputs, 24V DC, 1-wire
• Number of Inputs: 32 Channels
• Input Voltage Type: DC
• Input Voltage Range: 0 ... 30 V DC
• Nominal Input Voltage: 24 V DC
• Input Current: 5 mA (Typical)
• Supply Voltage: 20.4 … 28.8 V DC (Module Power)
• Delay Time (τ): Configurable from 0.1 to 32 ms
• Degree of Protection: IP20
• EAN: 4016779649179

Physical Dimensions & Weight

• Product Net Dimensions (L x H x W): 62 mm x 76 mm x 67.5 mm
• Product Net Weight: 0.1 kg
• Package Dimensions (L x H x W): 84 mm x 72 mm x 71 mm
• Package Gross Weight: 0.124 kg
• Package Units: 1 carton

Compliance & Certifications

• CE Declaration: 3ADR980146
• RoHS: Compliant with EU Directive 2011/65/EU and Amendment 2015/863
• REACH: Contains substances > 0.1% (Declaration: 3ADR980139)
• SCIP Number (Germany): 4c0d2eb2-95de-4c2f-8a8e-3c148ea4248f
• WEEE Category: 5 (Business-to-Business)
• Customs Number (CN8): 85389091

Industry Classifications

• eClass: 27-24-22-04
• ETIM (8/9/10): EC001419 - PLC digital I/O-module
• UNSPSC: 32151705

Ordering Information

• Minimum Order Quantity: 1 piece
• Order Multiple: 1 piece
• Selling Unit: Piece
• Made To Order: No (Standard Stock Item)

Module Features & Applications

• High density of 32 inputs in a compact module saves space in control cabinets.
• Configurable input delay (0.1 to 32 ms) allows filtering of contact bounce or noisy signals.
• Wide input voltage range (0-30V DC) accommodates standard 24V DC industrial signals.
• Low input current (5 mA) minimizes load on field sensors and switches.
• Designed for integration into the ABB S500 I/O system for distributed automation.
• Ideal for monitoring pushbuttons, limit switches, proximity sensors, and relay contacts in machinery and process control.

For technical documentation or to order the ABB DI524 (1SAP240000R0001), contact our sales team.

Contact: Email sales@nex-auto.com or WhatsApp +86 153 9242 9628.
