6AV2124-0XC02-0AX1 Touch Panel Siemens

In stock (19 units), ready to be shipped
  • Vendor:

    Siemens

  • Type:

    Touch Panel

  • Country of Origin:

    DE

  • Dimensions:

    17*15*3cm

  • Weight:

    1000 g

  • Tags: Touch panel

6AV2124-0XC02-0AX1 Comfort Panel

Display Specifications

  • Display Colors: 16,777,216 colors for vibrant graphics
  • Display Width: 475.2 mm viewing area
  • Display Height: 267.3 mm viewing area
  • Backlight Life: 30,000 hours MTBF at 25°C
  • Dimming Capability: 0-100% adjustable backlight

Control & Operation Features

  • Touch Technology: Analog-resistive touch screen
  • Onscreen Keyboards: Numeric and alphanumeric input
  • Direct Keys: 40 touch buttons as S7 input I/O
  • Mounting Options: Vertical, portrait, and landscape formats
  • Maximum Tilt: 35° angle without external ventilation
  • Audio Output: Built-in speaker for audio feedback

Technical Specifications

  • Power Supply: 24V DC nominal voltage
  • Voltage Range: 19.2V to 28.8V DC operating range
  • Current Consumption: 1.7A typical operating current
  • Power Consumption: 41W active power input
  • Processor Type: X86 architecture
  • User Memory: 24MB configuration storage
  • Real-time Clock: Hardware clock with 6-week backup

Connectivity & Interfaces

  • Industrial Ethernet: 2 ports with integrated switch
  • PROFIBUS/MPI: RS-485 interface included
  • USB Ports: 2 x USB 2.0 host interfaces
  • Memory Slots: 2 SD card slots for expansion
  • Protocol Support: PROFINET, EtherNet/IP, MODBUS
  • Web Features: HTTP, HTTPS, HTML, XML support

Environmental Protection

  • Front Protection: IP65 rating for dust and water jets
  • Rear Protection: IP20 rating for general use
  • NEMA Rating: Type 4 and 4X at the front
  • Operating Temperature: 0°C to 45°C vertical mounting
  • Storage Temperature: -20°C to 60°C range
  • Humidity Range: Up to 90% non-condensing

Software & Configuration

  • Operating System: Windows Embedded Compact 2013
  • Configuration Software: WinCC Comfort V14 SP1 and higher
  • Language Support: 32 online and project languages
  • Alarm Capacity: 6,000 bit messages, 200 analog messages
  • Recipe Management: 500 recipes with 1,000 data records
  • Variable Capacity: 4,096 variables per device

Contact our sales team for pricing and technical support: sales@nex-auto.com
